Hirose DF3 Series Straight Through Hole PCB Header, 8 Contacts, 2 mm Pitch, 1 Row, Shrouded DF3A-8P-2DSA

Hirose DF3A-8P-2DSA is a straight through hole PCB header connector from the DF3 series, featuring 8 contacts spaced at a 2 mm pitch in a single row layout. Manufactured with a high-quality polyamide housing, this shrouded connector is designed to ensure secure and reliable electronic board connections in industrial, manufacturing, and laboratory equipment.

The connector supports a current rating of 3A and a voltage rating of 250V. Contacts are formed from copper alloy with tin plating to optimize conductivity while providing resistance to corrosion and wear. The through hole mount type, with a pin diameter of 0.8 mm, enables strong mechanical and electrical connections through solder termination methods.

Operating temperature ranges from -30°C to 85°C make this component suitable for diverse environments including industrial electronics, power distribution boards, instrumentation, and automation systems. The connector system supports both board-to-board and wire-to-board configurations, enhancing its versatility for various layout designs.

Key features include the shrouded design which protects contacts and aids alignment during assembly, male contact gender for compatibility with mating connectors, and compliance with no specific external standards or approvals.

This PCB Header is manufactured in Japan, ensuring high build quality and reliability. It is an essential component in electronics manufacturing, prototyping, and repair operations.

Offers a current rating of 3A to handle typical electronic circuit currents. Constructed with durable polyamide housing for electrical insulation and mechanical strength. Features shrouded connector design for secure and precise mating.

Contact pins are made of copper alloy and plated with tin for excellent conductivity and corrosion resistance. Operates reliably in temperature ranges from -30°C up to 85°C. Supports board-to-board and wire-to-board connector systems.

Designed for through hole mounting with 0.8 mm pin diameter and a standard 2 mm row pitch. Termination type is solder, providing a robust electrical and mechanical connection. Male contact gender suitable for mating with corresponding connectors.

Rated voltage of 250V suitable for various electronic applications. Explore the Hirose brand catalog on EnvMart for more connectors and electronic components optimised for industrial and commercial electronics applications.
