Panasonic PCB Power Relay 24V DC Coil 10A Switching Current DPDT Contact Configuration ADJ56024
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 16.5mm |
| Length | 29mm |
| Model | ADJ56024 |
| Width | 13mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Series | ADJ |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | Through Hole |
| Typical Applications | Brake circuits, motor control, time switches |
| Contact Resistance | 100mΩ |
| Standards/Approvals | VDE, UL, RoHS |
| Coil Resistance | 2304Ω |
| Coil Voltage | 24V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 250mW |
Key Features
- This relay features a dual pole double throw (DPDT) contact arrangement.
- It supports switching AC voltage up to 250V AC and a switching power of 4000VA.
- The relay is suitable for through-hole mounting on PCB boards.
- Operating temperature range is from -40°C to 70°C, ensuring reliable performance in diverse conditions.
- Gold plated contacts offer low contact resistance of 100mΩ, enhancing signal reliability.
- Coil resistance of 2304Ω and power consumption of 250mW enable energy efficient operation.
- Compact dimensions of 29mm length, 13mm width, and 16.5mm height optimize PCB space usage.
- Certified to standards including VDE, UL, and RoHS compliance for safety and environmental regulations.
Product Description
Panasonic ADJ56024 PCB Power Relay features a 24V DC coil with a 10A switching current and DPDT contact configuration, making it ideal for printed circuit board mount applications. This relay belongs to the ADJ series known for compactness and high capacity within a 29x13x16.5mm form factor.
It accommodates switching AC voltages up to 250V AC and switching power of 4000VA, suitable for industrial automation, electric power devices, household appliance networks, and time switch controls. The through-hole terminal type facilitates reliable PCB mounting and mechanical stability.
This relay operates efficiently with a coil resistance of 2304 Ohms and coil power consumption of 250mW. Its operating temperature range from -40°C to 70°C enables robust functionality across varied environmental conditions. Gold plated contacts minimize signal loss by maintaining a contact resistance of 100mΩ, ensuring durability and performance.
Manufactured in Japan, the ADJ56024 relay complies with VDE, UL, and RoHS standards, confirming safety and environmental compliance. Applications typically include brake circuits, motor controls, and precise time delay switches in industrial and commercial systems.
Dual pole double throw (DPDT) contact configuration provides versatile switching options. Compact and space-saving design suitable for various PCB designs. High switching capacity with 10A current rating for demanding electrical circuits.
Energy-efficient coil with low power consumption. Wide operating temperature range for industrial reliability. Gold plated contacts ensure minimal contact resistance and long service life. Wide range of industrial and household applications.
Explore more Panasonic products and solutions in our Relays & Contactors category at EnvMart for reliable and precise electrical components.
