Semtech Uni-Directional TVS Diode Array 500 W, 8-Pin SOIC SRDA05-6.TBT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Semtech |
| Height | 1.5mm |
| Length | 5mm |
| Model | SRDA05-6.TBT |
| Width | 4mm |
| Mount Type | Surface |
| Series | SR |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -55°C |
| Pin Count | 8 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 20V |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 6V |
| Maximum Reverse Stand-off Voltage Vwm | 5V |
| Peak Pulse Power Dissipation Pppm | 500W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 25A |
| Maximum Reverse Leakage Current | 10μA |
Key Features
- This TVS diode array has a single diode configuration for uni-directional surge suppression.
- It operates at a minimum breakdown voltage of 6 volts with a maximum reverse stand-off voltage of 5 volts.
- The device features a clamping voltage of 20 volts and supports a peak pulse current of 25 amps.
- Designed for surface mounting, the compact SOIC package measures 5 mm in length, 4 mm in width, and 1.5 mm in height.
- It withstands operating temperatures from -55°C up to 125°C, ensuring durability in harsh environments.
- The diode array includes ESD protection compliant with IEC standards for air and contact discharges.
- It effectively protects up to four I/O lines with low capacitance, making it ideal for sensitive electronics.
- Reliable surge and ESD protection are provided without automotive certification, suited for industrial and electronic semiconductor applications.
Product Description
Semtech SRDA05-6.TBT is a uni-directional TVS diode array designed for surge and electrostatic discharge (ESD) protection in electronic circuits. It offers 500 watts peak pulse power dissipation in a compact 8-pin SOIC surface-mounted package, making it suitable for protecting sensitive components in various applications including industrial electronics, power supplies, and telecommunication equipment.
This diode array features a single diode configuration with a minimum breakdown voltage of 6 volts and maximum reverse stand-off voltage of 5 volts, ensuring efficient suppression of voltage spikes. It provides a clamping voltage of 20 volts and can handle peak pulse currents up to 25 amps, effectively safeguarding connected lines from transient surges.
The device is capable of operating within a wide temperature range from -55°C to 125°C, offering high reliability in harsh environments.
Its low capacitance design makes it ideal for protecting up to four I/O lines without affecting signal integrity, thus suitable for sensitive data and communication lines. While the product is not automotive standard certified, it is well suited for various industrial, laboratory, and manufacturing applications requiring robust surge protection.
Package dimensions are compact with 5 mm length, 4 mm width, and 1.5 mm height enabling flexible PCB layout designs. The 8-pin SOIC format supports surface mount technology (SMT) assembly for efficient manufacturing.
This TVS Diode Array offers excellent transient voltage suppression to protect electronic components and circuits. Compact SOIC package supports surface mount assembly and space-saving designs. Compliance with international ESD and surge immunity standards ensures reliable protection.
Wide operating temperature range enables long-term durability and performance. Low capacitance array protects multiple I/O lines with minimal signal interference. Suitable for industrial, manufacturing, communication, and power electronics applications.
Explore more semiconductor components and surge protection devices in the Electronics & Electricals category on EnvMart for comprehensive solutions.
