STMicroelectronics 1-Element Uni-Directional Transient Voltage Suppressor TVS Diode 600 W, 2-Pin DO-214 SM6T6V8A

Name: STMicroelectronics 1-Element Uni-Directional Transient Voltage Suppressor TVS Diode 600 W, 2-Pin DO-214 SM6T6V8A
Brand: STMicroelectronics
SKU: 126538
Price: 0.12 USD
Availability: InStock



Category TVS Diode Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	2.45mm
Length	4.6mm
Model	SM6T6V8A
Width	3.95mm
Mount Type	Surface
Series	SM6T
Maximum Operating Temperature	150°C
Package Type	DO-214
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Clamping Voltage VC	13.4V
Diode Configuration	Single
Direction Type	Uni-Directional
Minimum Breakdown Voltage Vbr	6.45V
Maximum Reverse Stand-off Voltage Vwm	5.8V
Peak Pulse Power Dissipation Pppm	600W
Test Current It	10mA
Maximum Peak Pulse Current Ippm	298A
Maximum Reverse Leakage Current	20μA

Key Features

The diode has a peak pulse power dissipation rating of 600 watts.
It features a 2-pin DO-214 surface mount package compatible with standard PCB assembly processes.
Minimum breakdown voltage is specified at 6.45 volts ensuring precise voltage clamping performance.
Operating temperature range extends from -55°C to 150°C for robust industrial use.
The device can handle high peak pulse current up to 298 amperes for transient surge protection.
Maximum reverse leakage current is very low at 20 microamperes, contributing to circuit efficiency.
Compact dimensions of 4.6 mm length, 3.95 mm width, and 2.45 mm height facilitate space-saving designs.
Clamping voltage is 13.4 volts to protect sensitive components from voltage spikes.

Product Description

The STMicroelectronics SM6T6V8A is a highly reliable 1-element uni-directional transient voltage suppressor (TVS) diode, optimized for protecting sensitive electronic devices and circuits against transient overvoltage conditions such as voltage spikes and electrostatic discharges.

This 600-watt rated TVS diode is provided in the compact DO-214 surface mount package with 2 pins, facilitating easy integration into modern PCB layouts and automated manufacturing processes. Its minimal footprint of 4.6 x 3.95 x 2.45 mm enables designers to implement effective surge protection without sacrificing valuable board space.

Operating over a broad temperature range from -55°C to 150°C, the SM6T6V8A TVS diode is suitable for various demanding industrial and commercial environments, including power supplies, telecommunications equipment, consumer electronics, and automotive applications that do not require automotive standard compliance.

Featuring a minimum breakdown voltage of 6.45 volts and a maximum reverse stand-off voltage of 5.8 volts, this diode ensures rapid clamping action at a clamping voltage of 13.4 volts. It can safely dissipate transient pulse power peaks up to 600 watts and handle peak pulse currents up to 298 amperes, thereby ensuring effective suppression of transient surges and safeguarding downstream circuitry.

The very low maximum reverse leakage current of 20 microamperes minimizes power losses during normal operation. This uni-directional TVS diode is a key component for transient voltage protection in DC circuits and other polarity-critical applications, enhancing system reliability and longevity.

The diode configuration is single element uni-directional for focused transient suppression. Surface mount mount type and standard DO-214 package ensure compatibility with automated SMT assembly. Specified operating and storage temperature ranges guarantee durability in harsh environments.

High peak pulse power and current ratings make it suitable for protecting power lines and sensitive electronics. The series SM6T family provides standardized voltage ratings and form factors for diverse design needs. Ideal for industrial, commercial, and general electronics applications requiring transient voltage protection, the SM6T6V8A TVS Diode is a trusted choice for design engineers.

Explore more semiconductor protection components and related electronic components in the Electronics & Electricals category on EnvMart for comprehensive sourcing solutions.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The peak pulse power dissipation rating of this diode is 600 watts.

The clamping voltage of the SM6T6V8A is 13.4 volts, which helps protect sensitive components from voltage spikes.

The minimum breakdown voltage for this diode is specified at 6.45 volts.

The operating temperature range of this model extends from -55°C to 150°C.

This model can handle peak pulse currents up to 298 amperes.

The dimensions of the SM6T6V8A diode are 4.6 mm in length, 3.95 mm in width, and 2.45 mm in height.

The diode is provided in a DO-214 surface mount package, which is compatible with standard PCB assembly processes.

The maximum reverse leakage current is very low at 20 microamperes, contributing to circuit efficiency.

Yes, the SM6T6V8A is suitable for various demanding industrial and commercial environments, including power supplies and telecommunications equipment.

This diode has a single element configuration, designed for focused transient suppression.
