ASSMANN WSW 20-Way IDC Connector Male for Cable, 2 Row, 250V AC, 1A, Shrouded, Right Angle AWHC 20-0111-T
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250V ac |
| Brand | ASSMANN WSW |
| Orientation | Right Angle |
| Current | 1A |
| Model | AWHC 20-0111-T |
| Mount Type | Cable |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | AWHC |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin, Nickel, Gold |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Connector Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- Features 20 male contacts arranged in 2 rows for compact connectivity.
- Shrouded design ensures safe and reliable connections.
- Right angle orientation for efficient cable routing in applications.
- Contacts plated with tin, nickel, and gold for improved conductivity and corrosion resistance.
- Engineered with brass contacts and polybutylene terephthalate housing for durability.
- Operates reliably from -40°C to a maximum of 105°C temperature.
- Termination type is IDC, facilitating easy and secure cable connection.
- Suitable for cable mount with a pitch of 2.54mm inline with standard IDC configurations.
Product Description
ASSMANN WSW AWHC 20-0111-T is a 20-way IDC Connector designed for male cable connections with 2 rows of contacts, rated for 250V AC and 1A current. The connector is shrouded and features a right angle orientation to facilitate efficient assembly and cable management in electronic components and power connector applications.
It is constructed with brass contact material and a durable polybutylene terephthalate housing ensuring long-lasting performance in demanding environmental conditions. Contact plating with tin, nickel, and gold plating provides enhanced conductivity and protection against corrosion.
This IDC connector supports a pitch of 2.54mm, compliant with common connector standards, making it an ideal choice for PCB connectors and wire housing solutions in electronics manufacturing and repair.
The operating temperature range from -40°C up to 105°C allows it to perform reliably across a wide range of industrial and commercial applications, including electronic assembly, power connectors, and cable harnesses.
Features 20 male contacts arranged in 2 rows for compact connectivity. Shrouded design ensures secure and safe wire housing. Right angle orientation aids in cable management and space saving. Contact plating with tin, nickel, and gold enhances conductivity and resistance.
Robust brass contacts and polybutylene terephthalate housing ensure durability. Broad operating temperature range from -40°C to 105°C for versatile use. IDC termination type enables quick and reliable cable connections. 2.54mm pitch aligns with standard printed circuit board layouts.
This product is manufactured in China and is suitable for industrial, manufacturing, electronic, and laboratory applications demanding precision and reliability in electrical connections. The ASSMANN WSW IDC connector line provides dependable solutions tailored for professional electronics assembly environments.
Explore more IDC Connectors and related products in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The IDC connector is rated for 250V AC.
This model has a current capacity of 1A.
It operates reliably within a temperature range of -40°C to 105°C.
The connector features 20 male contacts arranged in 2 rows.
It uses IDC (Insulation Displacement Connector) termination for easy cable connection.
The contacts are made of brass, and the housing is constructed from polybutylene terephthalate.
The pitch of this connector is 2.54mm, aligning with standard configurations.
This model features a right angle orientation for efficient cable routing.
The connector is shrouded, which ensures safe and reliable connections.
This product is manufactured in China.
It is suitable for industrial, manufacturing, electronic, and laboratory applications requiring reliable electrical connections.
The contacts are plated with tin, nickel, and gold for enhanced conductivity and corrosion resistance.
