ASSMANN WSW 14-Way IDC Connector Female for Cable, Double Row, 3A, 250V ac, Gold and Nickel Plated AWP 14-7240-T

ASSMANN WSW AWP 14-7240-T is a 14-way insulation displacement contact (IDC) connector designed for female cable connections, featuring a double row layout for optimized contact arrangement and reliable electrical performance. This connector is rated for 3A current and operates at up to 250V ac, making it suitable for various electronics and power applications.

The housing is made from polybutylene terephthalate (PBT) with a UL94V-0 rating, ensuring robust mechanical protection and flame resistance. Contacts are machined from brass and plated with a combination of nickel and gold for excellent durability, conductivity, and corrosion resistance.

The connector's pitch is 2.54mm x 2.54mm providing standard spacing for typical ribbon cables. The right angle orientation allows for easier cable management in confined or complex assemblies, while the shrouded design protects contacts and enhances safety during handling and use. This connector is compatible with IDC ribbon cables and is engineered for quick and efficient termination without soldering.

Operating temperature range is broad, from -40°C minimum up to 105°C maximum, enabling use in demanding industrial, commercial, and electronic environments. This product is ideal for applications requiring reliable cable connections such as industrial control systems, telecommunications equipment, and consumer electronics.

Manufactured in China, this connector complies with relevant standards, providing consistent quality and performance. The AWP series by ASSMANN WSW is well regarded for combining high electrical integrity with mechanical resilience.

Features 14 contacts arranged in two rows for reliable connections. Constructed with brass contacts and polybutylene terephthalate housing for durability. Gold and nickel plating on contacts to ensure corrosion resistance and conductivity.

Rated for operating temperatures ranging from -40°C to 105°C. Shrouded design provides enhanced protection and right angle orientation facilitates easy cable routing. Utilizes insulation displacement contact (IDC) termination for quick and efficient assembly.

Suitable for use in electronic assemblies, PCB connectors, power and signal applications. Manufactured in China with adherence to quality standards for electronic components. Browse EnvMart’s Electronics Components category for more IDC Connectors and cable solutions designed for industrial, laboratory, manufacturing, and commercial use.
