Amphenol Communications Solutions Dubox Series Straight Surface PCB Socket, 16-Contact, 1 Row, 2.54 mm Pitch 91601-316LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 1kV |
| Brand | Amphenol Communications Solutions |
| Orientation | Straight |
| Model | 91601-316LF |
| Mount Type | Surface |
| Housing Material | Glass Filled Thermoplastic |
| Contact Material | Bronze |
| Series | Dubox |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Connector System | Board-to-Board |
| 89898-3xxLF | SMT, Dual Row, Dual Entry |
| 91601-3xxLF | SMT, Single Row, Top Entry |
Key Features
- Designed for surface mount technology with straight orientation.
- Constructed with a glass filled thermoplastic housing for durability.
- Contacts made from bronze with gold plating ensure corrosion resistance.
- Rated for 1kV voltage and compliant with RoHS standards.
- Operates reliably from -65°C up to 125°C temperature range.
- Part of the Dubox series known for low profile SMT vertical receptacles.
- Provides a pre-stressed dual beam contact design for low insertion force.
- Ideal for board-to-board connector systems in electronic components.
Product Description
Amphenol Communications Solutions 91601-316LF Dubox Series Straight Surface PCB Socket is a high-quality connector designed for board-to-board interconnections in electronic devices. Featuring 16 contact points arranged in a single row with a 2.54 mm pitch, this socket uses surface mount technology with a straight orientation to ensure a secure and reliable solder termination.
The housing material is a robust glass filled thermoplastic, providing mechanical strength and durability for industrial applications. Contacts are made from bronze and plated with 0.76 μm gold on mating areas for excellent electrical contact and corrosion resistance, while the PCB tails are matte tin plated.
This PCB socket operates within a voltage rating of 1kV and can withstand operating temperatures ranging from -65°C to 125°C, making it suitable for demanding environments in manufacturing, communication, and electronic assembly industries.
The Dubox series is recognized for its low profile SMT vertical receptacles, featuring a pre-stressed dual beam contact design that provides low insertion force for ease of use and long-term reliability. It is an ideal component for complex board-to-board connector systems and electronic component manufacturing.
Designed for surface mount technology with straight orientation. Glass filled thermoplastic housing enhances mechanical stability. Bronze contacts with gold plating ensure reliable and corrosion-resistant electrical connections.
Compliant with RoHS environmental standards. Wide operating temperature range of -65°C to 125°C for robust performance. Voltage rated at 1kV for high voltage applications. Pre-stressed dual beam contact design lowers insertion force.
Suitable for industrial, laboratory, communication, electronics manufacturing use cases.
This product is manufactured in France and represents the high standards of Amphenol Communications Solutions' Dubox series. It is strongly recommended for engineers and procurement specialists seeking reliable PCB Sockets for advanced electronic assemblies.
Explore the extensive range of high-quality PCB connectors and related electronic components at EnvMart to support your industrial and commercial projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a voltage rating of 1kV, making it suitable for high voltage applications.
It operates reliably within a temperature range of -65°C to 125°C.
This socket features 16 contacts arranged in a single row.
The housing is made from glass filled thermoplastic, while the contacts are bronze with gold plating for corrosion resistance.
This model is designed for surface mount technology (SMT) with a straight orientation.
Yes, it is compliant with RoHS environmental standards.
The contact pitch for this model is 2.54 mm.
It uses solder termination for secure connections.
This socket is designed for board-to-board connector systems.
This product is manufactured in France.
It features a pre-stressed dual beam contact design that provides low insertion force for ease of use.
It is suitable for industrial, laboratory, communication, and electronics manufacturing applications.
