Texas Instruments Line Transceiver, Differential, Non-Inverting, 8-Pin SOIC, 4.5V-5.5V Supply, 50ns Propagation SN65HVD1176D
Specifications
| Country of Origin | Mexico |
|---|---|
| Brand | Texas Instruments |
| Height | 1.75mm |
| Length | 5mm |
| Model | SN65HVD1176D |
| Width | 3.98mm |
| Mount Type | Surface |
| Output type | Differential |
| Series | SN65HVD1176 |
| Input Type | Differential |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Polarity | Non-Inverting |
| IC Type | Line Transceiver IC |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | SN65 |
| Logic Function | Line Transceiver |
| Minimum Supply Voltage | 4.5V |
| Maximum High Level Output Current | -8mA |
| Maximum Propagation Delay Time @ CL | 50ns |
| Supply Current | 6mA |
| Maximum Low Level Output Current | 8mA |
Key Features
- Operates with a supply voltage range of 4.5V to 5.5V for versatility.
- Single channel line transceiver with differential inputs and outputs.
- Compact surface mount device with 8-pin SOIC packaging.
- Maximum propagation delay of 50 nanoseconds ensuring fast signal transmission.
- Designed to operate in temperatures from -40°C to 85°C for industrial applications.
- Supply current consumption is low at 6mA enhancing energy efficiency.
- Pin spacing and package dimensions enable easy PCB integration.
- Non-inverting output polarity aids in signal consistency for communication interfaces.
Product Description
Texas Instruments SN65HVD1176D line transceiver is a high-speed differential line transceiver IC designed for reliable communication in industrial and electronic systems. It features a non-inverting logic function with differential inputs and outputs, supporting precise data transmission with minimal delay.
This IC requires a minimum supply voltage of 4.5V and can operate up to 5.5V, making it adaptable to various power management designs. With a maximum propagation delay of 50 nanoseconds, it enables high-speed data rates over RS-485 and similar interfaces.
The device includes one communication channel in an 8-pin SOIC surface-mount package measuring 5mm by 3.98mm by 1.75mm, allowing compact integration on printed circuit boards in constrained spaces.
Operating temperature ranges from -40°C to 85°C, making it suitable for automotive, industrial, and other harsh environment applications. The supply current is a modest 6mA, contributing to energy-efficient operation in embedded and communication systems.
Operates on supply voltages from 4.5V to 5.5V. Non-inverting differential line transceiver functionality. High-speed propagation delay time of 50 nanoseconds. Surface mount SOIC package for compact PCB design. Wide operating temperature range from -40°C to 85°C.
Low supply current consumption for efficient power usage. Single channel electronic component for line interface applications. Manufactured with industrial quality standards in Mexico.
This transceiver is ideal for industrial, electronic, and communication applications requiring reliable differential signaling with high speed and low power. Browse EnvMart's extensive semiconductor and interface IC catalog for compatible components and solutions.
Explore more products in our Line Interface ICs category.
