Texas Instruments Line Transceiver CMOS Bipolar 16-Pin SOIC ISO3086DW

The Texas Instruments ISO3086DW is a high-speed line transceiver IC featuring CMOS logic family and bipolar polarity, housed in a 16-pin SOIC surface mount package. It is engineered for RS-485 communication interfaces requiring data rates of 10 Mbit/s or more, making it suitable for industrial control, automation, and communication systems.

This device operates within a supply voltage range of -0.3V to 6V and delivers a supply current of 286mA. Its maximum propagation delay time of 45 nanoseconds at capacitive loads ensures fast signal transitions, critical for high-speed data communication.

Designed with single-ended inputs and CMOS outputs, the ISO3086DW supports reliable digital signals with minimum distortion. Its bipolar polarity enhances signal integrity in noisy industrial environments. The compact physical dimensions (length 10.5mm, width 7.6mm, height 2.65mm) facilitate easy PCB integration and surface mounting using the SOIC package.

This line transceiver reliably functions across a wide operating temperature range from -45°C to 85°C, suitable for harsh industrial, laboratory, and instrumentation applications. While not certified for automotive standards, it is extensively used in control, measurement, and communication systems requiring stable line driver and receiver performance.

Operates on CMOS logic technology with bipolar polarity for signal robustness. Features 16-pin SOIC surface mount package for compact circuitry. Supply voltage range from minimum -0.3V to maximum 6V ensures flexibility. Consistent supply current of 286mA provides dependable power consumption.

Maximum propagation delay time of 45ns supports high-speed data transfer. Wide operating temperature range of -45°C to 85°C for harsh environments. Optimized for RS-485 network transceivers and line driver applications. Compact dimensions facilitate integration in electronic equipment.

Bipolar polarity design maintains transmission integrity amid noise. Surface mount technology ensures automated assembly compatibility.

This line transceiver is ideal for applications in industrial automation, laboratory instrumentation, communication equipment, and other environments demanding reliable, high-speed RS-485 data communication. Its compliance with CMOS technology and package configuration supports a broad range of system designs.
