Texas Instruments Timer Circuit, Surface Mount SOIC Package, 8-Pin, 3V to 15V Supply TLC555ID

Texas Instruments TLC555ID Timer Circuit is a highly stable and precise 8-pin SOIC package IC designed for generating accurate time delays or pulses. The device supports operation in monostable (one-shot) or astable (oscillator) modes with timing periods ranging from microseconds to several minutes. It operates reliably over a supply voltage range of 3V to 15V and performs with a maximum propagation delay of 75 nanoseconds under a 10 pF test condition.

The timer IC supports operation within a broad temperature range from -40°C to 85°C, making it suitable for various industrial and commercial applications. Its compact surface mount SOIC package (4.9 mm length, 1.58 mm height) allows efficient use in dense PCB layouts where space is at a premium.

This device contains a single internal timer and utilizes 8 pins for configuration and connectivity, facilitating flexible integrations into timing circuits such as pulse generation, delay timers, oscillator circuits, and waveform generation tasks. While it lacks specific automotive standard certifications, its robust design meets general industrial requirements.

The TLC series includes bipolar, low-power CMOS, and LinCMOS variants, providing options for applications demanding reduced power consumption or extended timing periods. The TLC555ID is part of the popular 555 timer family well known for precision and versatility in electronic circuit design.

The device operates as a stable monostable or astable timer generating precise time delays or pulses. It features a propagation delay of 75 nanoseconds at specified conditions. Operating temperature range is wide from -40°C to 85°C for industrial applications.

The compact SOIC package has dimensions of 4.9 mm length by 1.58 mm height for space-saving PCB layouts. It includes one internal timer and 8 pins for versatile circuit integration. Designed with a 10 pF propagation delay test condition for timing accuracy.

Suitable for automotive and industrial electronic timing circuits without automotive standard approval.

This timer IC is widely utilized in industrial, laboratory, electronic manufacturing, and embedded system applications where reliable and accurate timing is crucial. EnvMart offers this product to facilitate high-quality timing circuit designs with trusted Texas Instruments quality.
