Microchip dsPIC Microprocessor 16 bit MCU DSP 200 MHz 28-Pin SSOP dsPIC33CH128MP508

Microchip dsPIC33CH128MP508 is a dual-core 16 bit MCU and DSP microprocessor operating at 200 MHz, housed in a 28-pin SSOP surface mount package operating between 3 V to 3.6 V supply voltage. It is designed for high-efficiency embedded systems requiring both MCU and DSP capabilities on a single chip.

This microprocessor features a master core with up to 128KB program flash memory with ECC, 16KB RAM, and a slave core with 24KB program RAM and 4KB data RAM. The architecture enables code-efficient operations in both C and assembly languages, supported by 40-bit wide accumulators and fast 6-cycle divide operations.

Communication interfaces include 3 UART ports, 3 4-wire SPI/I2S, and CAN bus, allowing versatile connectivity options. The device supports various embedded system protocols such as DMX, LIN/J2602, and IrDA, making it suitable for complex communication requirements.

Robust safety features include watchdog timer (WDT), data memory ECC, clock fail-safe monitoring, and CRC error checking. Three low power modes (Sleep, Idle, Doze) provide energy-efficient operation, while up to 12-channel high-speed PWMs with 250ps resolution enhance control performance.

Applications include embedded systems, LCD monitors, TVs, portable hub boxes, system monitoring, and communications equipment in industrial, commercial, and consumer electronics. The device is RoHS compliant, ensuring environmental safety standards.

Features dual 16-bit cores optimized for MCU and DSP operations. Maximum clock frequency is 200 MHz for high performance. Supports surface mount type SSOP package with 28 pins. Operating voltage ranges between 3 V and 3.6 V.

Operating temperature range from -40°C to 85°C ensuring industrial reliability. Includes multiple communication interfaces including UART, SPI, CAN bus. Equipped with memory: 64KB to 128KB program flash, 16KB RAM, and 24KB slave PRAM.

Offers advanced safety features such as ECC, WDT, CRC, DMT, fail-safe clock monitoring. Ideal for embedded systems, LCD monitors, TVs, portable hubs, and system monitoring. Explore more Microchip Microprocessors and embedded processing solutions on EnvMart to find the best fit for your application needs.
