Nexperia 75 V 500 mW Voltage Regulator Zener Diode Single Through Hole 2-Pin SOD-27 BZX79-C75,113

Nexperia BZX79-C75,113 75 V Voltage Regulator Zener Diode Single configuration is designed for through hole mounting in a 2-pin SOD-27 package delivering 500 mW maximum power dissipation. It is engineered for voltage regulation and provides nominal Zener voltage of 75 V with a voltage tolerance of ±5% and maximum Zener impedance of 255 Ω.

This diode supports test current of 2 mA with a typical voltage temperature coefficient of 80.2 mV/°C ensuring stable operation across temperature ranges from -65°C to 200°C. It features a very low maximum reverse leakage current of 50 nA contributing to energy efficiency and reliability in sensitive electronic circuits.

The compact device dimensions (length 4.25 mm and height 1.85 mm) allow its use in various industrial and commercial electronics requiring precise voltage regulation such as power supplies, instrumentation, and signal conditioning.

Applications of this Zener diode include voltage reference, clipping circuits, voltage stabilization in automotive, industrial, and consumer electronics. It is suitable for discrete semiconductor setups where reliable voltage limiting is needed.

This diode has a voltage regulator Zener type suitable for stable voltage applications. It features a 2-pin through hole SOD-27 package for easy PCB mounting. Maximum Zener impedance is 255 Ω ensuring voltage stability under load.

Test current is 2 mA and the device maintains performance between -65°C and 200°C. Maximum reverse leakage current is very low at 50 nA for minimal power loss. The diode length is 4.25 mm and height is 1.85 mm, compact for integration.

It complies with BZX79 series specifications from Nexperia. This product is made in China and supplied as new condition. Discover more high-quality semiconductor components in the Zener Diodes category at EnvMart for your electronics design and manufacturing needs.
