Texas Instruments LMV324M/NOPB Operational Amplifier 1 MHz 14-Pin SOIC 5.5V
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.45mm |
| Length | 8.64mm |
| Model | LMV324M/NOPB |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | LMV324-N |
| Output Current | 40mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | 250 nA |
| Vos - Input Offset Voltage | 7 mV |
| Slew Rate | 1V/μs |
| Input Offset Current | 50 nA |
Key Features
- Comprises four independent operational amplifier channels in a 14-pin SOIC package.
- Designed for low power consumption with a 3V minimum supply voltage and 5.5V maximum.
- Offers a slew rate of 1V/μs for moderate speed signal amplification.
- Input bias current of 250 nA and input offset voltage of 7 mV enable precise operation.
- Operates reliably within -40°C to 85°C temperature range, suitable for industrial environments.
- Features output current capacity of up to 40 mA for driving loads.
- Complies with RoHS standards and meets Automotive Standard AEC-Q100.
- Compact dimensions of 8.64 mm length, 3.91 mm width, and 1.45 mm height.
Product Description
Texas Instruments LMV324M/NOPB is a quad low voltage operational amplifier designed for surface mount applications. The 14-pin SOIC package integrates four independent op-amps with a 1 MHz gain bandwidth product, making it suitable for signal conditioning, filtering, and amplification in electronic circuits.
This device supports supply voltages ranging from 3V to a maximum of 5.5V and features a slew rate of 1V/μs, facilitating stable and efficient performance in both consumer and industrial electronics setups. With input bias currents of 250 nA and an input offset voltage of 7 mV, it ensures accurate signal processing with minimal error.
Designed for robustness, the LMV324M/NOPB operates over an extended temperature range of -40°C to 85°C, meeting requirements for harsh environmental conditions. The operational amplifier offers an output current capacity of 40 mA, enabling it to drive intermediate loads effectively.
The device complies with RoHS environmental standards and is qualified to the Automotive Standard AEC-Q100, underscoring its reliability for automotive and industrial applications. Its compact SOIC package measures 8.64 mm in length, 3.91 mm in width, and 1.45 mm in height, providing space-saving integration into circuit designs.
Comprises four independent op-amp channels for diverse circuit applications. Support for low voltage operation enhances energy efficiency in portable devices. Wide operating temperature range ensures stable performance in demanding environments.
Meets RoHS and automotive standards for quality and environmental compliance. Compact SOIC packaging for flexible PCB layout and assembly. Slew rate and bandwidth suitable for moderate frequency signal processing. Designed for surface mount technology for modern circuit manufacturing.
This Operational Amplifier is ideal for industrial, automotive, and general electronic circuit applications requiring reliable, precision analog signal amplification. Explore the broad range of Texas Instruments semiconductor products in the EnvMart catalog to find matching industrial-grade components for your design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 1 MHz, making it suitable for moderate frequency signal processing applications.
It has an output current capacity of up to 40 mA, allowing it to effectively drive intermediate loads in various applications.
This model supports a supply voltage range from a minimum of 3V to a maximum of 5.5V, which is suitable for low voltage applications.
It operates reliably within a temperature range of -40°C to 85°C, making it suitable for industrial environments.
The compact dimensions are 8.64 mm in length, 3.91 mm in width, and 1.45 mm in height, facilitating space-saving integration into circuit designs.
The input bias current for the LMV324M/NOPB is 250 nA, which helps ensure accurate signal processing with minimal error.
The slew rate of this model is 1V/μs, which allows for stable and efficient performance in signal amplification.
The input offset voltage is 7 mV, contributing to its precise operation in various applications.
This operational amplifier is packaged in a 14-pin SOIC format, designed for surface mount applications.
Yes, it complies with RoHS standards and meets the Automotive Standard AEC-Q100, ensuring reliability for automotive and industrial applications.
This operational amplifier comprises four independent channels, allowing for diverse circuit applications.
The input offset current for the LMV324M/NOPB is 50 nA, which is relevant for ensuring precision in signal processing.
