HARWIN Datamate L-Tek Series Right Angle Through Hole PCB Header, 4 Contacts, 2 mm Pitch, 1 Row, Shrouded M80-8430442
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 120V |
| Brand | HARWIN |
| Orientation | Right Angle |
| Current | 3A |
| Model | M80-8430442 |
| Mount Type | Through Hole |
| Housing Material | Polyphenylene Sulphide |
| Contact Material | Phosphor Bronze |
| Series | Datamate L-Tek |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3mm |
Key Features
- The header is shrouded for added protection and has 1 row configuration.
- Constructed with phosphor bronze contacts plated with gold for reliable connectivity.
- Designed for board-to-board and wire-to-board connector systems with through hole mount type.
- Supports a current rating of 3A and voltage of 120V.
- Housing is made of durable polyphenylene sulphide suitable for harsh environments.
- Operates reliably between temperatures of -55°C to 125°C.
- Tail pin length of 3mm facilitates solder termination.
- Right angle orientation enables compact PCB layouts.
Product Description
HARWIN M80-8430442 Datamate L-Tek Series Right Angle Through Hole PCB Header features 4 contacts with 2 mm pitch in a 1 row, shrouded design. It is designed for high-reliability applications where safety and durability are essential, such as industrial, aerospace, and military systems.
The connector uses gold-plated phosphor bronze contacts to provide superior conductivity and resistance to corrosion. The housing is produced from polyphenylene sulphide, ensuring excellent resistance to mechanical and thermal stresses.
The right angle, through-hole mounting style allows easy integration into printed circuit boards with space-saving orientation. The 3A current rating and 120V voltage capacity make it suitable for a wide range of electronic components and assemblies.
Operating reliably within a wide temperature range from -55°C to 125°C, this header is ideal for harsh environments with high vibration, shock, and acceleration loads. The Datamate series is known for its four-finger beryllium copper contacts, providing stable and secure connections for extended mating cycles without performance degradation.
The shrouded design enhances contact protection, preventing accidental shorts and improving mechanical stability. The product complies with military and industrial standards such as BS9525-F0033, MIL C 55302, and CEC 75101-008, making it suitable for COTS (commercial off-the-shelf) and critical applications.
The header features 4 gold-plated phosphor bronze contacts in a right angle, single row arrangement. Housing made of polyphenylene sulphide offers high durability and heat resistance. Supports board-to-board and wire-to-board connections with secure four-finger contacts.
Rated for 3A current and 120V voltage with solder termination on 3mm tail pins. Functions reliably in operating temperatures ranging from -55°C to 125°C.
This HARWIN Datamate L-Tek PCB header is a robust choice for industrial, aerospace, military, and commercial electronic assembly applications. Explore more of HARWIN connectors and PCB Headers on EnvMart for your next project.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 3A and a voltage rating of 120V.
The contacts are constructed from phosphor bronze and are plated with gold for reliable connectivity.
It operates reliably within a temperature range of -55°C to 125°C.
This header features a through hole mount type, allowing for easy integration into printed circuit boards.
The header has 4 contacts arranged in a single row configuration.
The contacts have a pitch size of 2 mm.
The tail pin length is 3 mm, facilitating solder termination.
Yes, the housing is made of polyphenylene sulphide, which provides excellent resistance to mechanical and thermal stresses, making it suitable for harsh environments.
It supports both board-to-board and wire-to-board connector systems.
This model features a right angle orientation, allowing for compact PCB layouts.
It complies with military and industrial standards such as BS9525-F0033, MIL C 55302, and CEC 75101-008.
It is designed for high-reliability applications, including industrial, aerospace, and military systems.
