HARWIN Datamate L-Tek Series Right Angle Through Hole PCB Header, 14 Contacts, 2 mm Pitch, 2 Row, Shrouded M80-8511442
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 120V |
| Brand | HARWIN |
| Orientation | Right Angle |
| Current | 3A |
| Model | M80-8511442 |
| Mount Type | Through Hole |
| Housing Material | Polyphenylene Sulphide |
| Contact Material | Phosphor Bronze |
| Series | Datamate L-Tek |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 14 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3mm |
Key Features
- Designed for high reliability in harsh environments with four finger Beryllium Copper contacts.
- Operates at up to 120V and 3A, suitable for board-to-board and wire-to-board connections.
- Housing made of durable Polyphenylene Sulphide to withstand vibration and shock.
- Gold-plated phosphor bronze contacts ensure excellent conductivity and corrosion resistance.
- Features a 3 mm tail pin length and polarized mouldings for correct insertion.
- Operates reliably between -55°C and 125°C for wide industrial use.
- Shrouded, right angle orientation minimizes PCB footprint and improves mechanical support.
- Complies with industry standards including BS9525-F0033 and MIL C 55302 for demanding applications.
Product Description
HARWIN M80-8511442 Datamate L-Tek Series Right Angle Through Hole PCB Header is engineered for industrial and electronic applications requiring high durability and reliability. This connector features 14 male contacts arranged in 2 rows with a 2 mm pitch, making it ideal for dense circuit board layouts.
The housing is constructed from Polyphenylene Sulphide, supporting mechanical strength and resistance to environmental stress. Contacts are made from phosphor bronze and plated with gold to ensure long-lasting electrical connectivity with minimal signal degradation. The four finger beryllium copper contact design provides exceptional mating cycle performance and vibration resistance.
This PCB header supports through hole mounting with a right angle orientation, optimized for board-to-board and wire-to-board systems, with a compact 3 mm tail pin length. It safely operates up to 120 V and 3 A across a broad temperature range from -55°C to 125°C, suitable for harsh industrial environments.
The shrouded design prevents accidental contact during handling and operation, improving system safety and reliability. Additionally, the connector meets multiple industry standards such as BS9525-F0033 and MIL C 55302, ensuring compatibility and trustworthiness in commercial off-the-shelf (COTS) applications.
Designed for harsh environments with high vibration and shock tolerance. Gold-plated phosphor bronze contacts for consistent conductivity. Robust Polyphenylene Sulphide housing enhances durability. Shrouded, polarized design for secure and safe connections.
Supports 14 contacts in 2 rows with 2 mm pitch spacing. Right angle orientation optimizes PCB layout density. Meets stringent industry standards for reliability.
This PCB header is suitable for industrial, commercial electronics, manufacturing, and other high-performance applications requiring durable and reliable interconnect solutions. Browse EnvMart's extensive catalog for more HARWIN connectors and related components to complete your system design.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates at a maximum voltage of 120V and a current of 3A.
The connector features a 2 mm pitch and includes 14 contacts arranged in 2 rows.
The housing is made of Polyphenylene Sulphide, while the contacts are made from phosphor bronze and gold-plated for conductivity.
It operates reliably between -55°C and 125°C, making it suitable for harsh industrial environments.
The shrouded design prevents accidental contact during handling and operation, improving system safety and reliability.
This model supports through hole mounting, optimized for board-to-board and wire-to-board connections.
The tail pin length is 3 mm, facilitating secure soldering during installation.
It complies with BS9525-F0033 and MIL C 55302 standards, ensuring reliability in demanding applications.
This model features a right angle orientation, which helps to minimize PCB footprint and improve mechanical support.
It is designed for board-to-board and wire-to-board connections, making it versatile for various applications.
This model utilizes solder termination, ensuring a secure connection to the PCB.
The country of origin for this product is the United Kingdom.
