HARWIN M80 Series Straight Through Hole PCB Socket, 2-Contact, 1 Row, 2 mm Pitch, 12A Current, Nylon Housing M80-8400245

HARWIN M80-8400245 Straight Through Hole PCB Socket is a high-quality 2-contact, 1-row PCB socket with 2 mm pitch, rated for 12A current and 120V operation. Designed with reliability in mind, it features a robust nylon housing and gold-plated beryllium copper alloy contacts that ensure excellent conductivity and durability, ideal for demanding industrial, manufacturing, and electronic environments.

This connector belongs to the Datamate Series and is specifically engineered for board-to-board applications requiring secure and long-lasting connections. The socket uses through-hole mounting with a straight orientation to facilitate easy assembly on printed circuit boards.

Its contacts utilize a four-finger clip design made from high reliability beryllium copper alloy, enhancing connection integrity even under conditions of vibration, shock, and acceleration. The gold plating on the contact surfaces aids signal quality and prevents corrosion, maintaining consistent performance over many mating cycles.

The operating temperature range from -55°C to 125°C ensures suitability for harsh and variable temperature conditions commonly found in industrial and automotive sectors. The socket complies with rigorous standards such as BS9525-F0033, MIL C 55302, and CEC 75101-008, underscoring its suitability for critical and certified applications.

The product is manufactured in the United Kingdom, reflecting quality production standards. Constructed with a nylon housing for insulation and durability. Gold-plated beryllium copper alloy contacts provide superior conductivity.

Designed for through-hole mounting with straight orientation. Operates efficiently between -55°C to 125°C temperature range. Suited for high reliability industrial and electronic applications. Complies with BS9525-F0033, MIL C 55302, and CEC 75101-008 standards.

Provides secure connection with a 4-finger clip contact design. Mates with all L-Tek SIL male headers of matching pitch and row configuration.

This HARWIN M80 Series PCB Socket is ideal for industrial tools production, electronics manufacturing, and harsh environment applications. It supports PCB assembly requiring high vibration resistance and long-term mating reliability. Explore similar PCB Sockets and connectors in the Electronics Components category on EnvMart for comprehensive connectivity solutions.
