Texas Instruments Operational Amplifier 6.4 MHz Gain Bandwidth 8-Pin SOIC Surface Mount TLV2462CD
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | TLV2462CD |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | TLV2462 |
| Output Current | 175mA |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 6.4MHz |
| Input Bias Current | 25 nA |
| Vos - Input Offset Voltage | 2.2 mV |
| Slew Rate | 1.6V/μs |
| Input Offset Current | 20 nA |
Key Features
- Dual-channel operational amplifier with 8-pin SOIC package.
- Gain bandwidth product of 6.4 MHz effectively supports high-frequency amplification.
- Operates with supply voltages from 3 V to 6 V.
- Low input bias current of 25 nA ensures precision in low-signal circuits.
- Wide operating temperature range from 0°C to 70°C.
- Low input offset voltage of 2.2 mV promotes accurate signal processing.
- Slew rate of 1.6 V/μs provides fast response to signal changes.
- Compliance with RoHS standards ensuring environmental safety.
Product Description
Texas Instruments TLV2462CD operational amplifier is a low-voltage dual-channel device, featuring a gain bandwidth product of 6.4 MHz and housed in an 8-pin SOIC surface mount package. Designed for applications requiring precise amplification with low power consumption, this op amp operates effectively between 3 V and 6 V supply voltages, making it ideal for portable and embedded electronic systems.
The device boasts low input bias and offset currents (25 nA and 20 nA respectively), along with a minimal input offset voltage of 2.2 mV, ensuring high accuracy in analog signal processing. Its slew rate of 1.6 V/μs enables rapid signal changes without distortion, which is crucial in audio, sensor, and control systems.
Compliant with RoHS standards and meeting the stringent automotive AEC-Q100 qualification, the TLV2462 series is suitable for industrial and automotive environments. Operating temperatures span from 0°C to 70°C, supporting reliable performance under typical operating conditions.
Its compact form factor (4.9 mm length, 3.91 mm width, and 1.58 mm height) allows dense PCB layouts and easy integration into electronic assemblies. The package's pin count of 8 simplifies routing for dual operational amplifiers on a single chip.
Dual 8-pin SOIC surface mount package. Gain bandwidth product of 6.4 MHz. Input bias current of 25 nA ensures low leakage. Operating voltage range: 3 to 6 V. Low input offset voltage of 2.2 mV. Slew rate of 1.6 V/μs supports fast signals.
Operating temperature from 0°C to 70°C. Compliance with RoHS environmental standards. Automotive certified to AEC-Q100 for reliability. Compact size supports high-density PCB design.
This operational amplifier is widely used in industrial electronics, automotive systems, communications equipment, and instrumentation. Texas Instruments ensures quality and consistency for demanding electrical component requirements.
Explore more Operational Amplifiers and semiconductor components at EnvMart for your advanced electronics design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TLV2462CD operational amplifier has a gain bandwidth product of 6.4 MHz, which supports high-frequency amplification.
It operates with supply voltages ranging from 3 V to 6 V, making it suitable for low-voltage applications.
The input bias current for the TLV2462CD is 25 nA, ensuring low leakage in low-signal circuits.
The maximum operating temperature for the TLV2462CD is 70°C, allowing it to function reliably in various environments.
The slew rate of this operational amplifier is 1.6 V/μs, which enables fast response to signal changes.
The input offset voltage for this model is 2.2 mV, promoting accurate signal processing.
The TLV2462CD is housed in an 8-pin SOIC surface mount package, facilitating compact PCB layouts.
Yes, it is compliant with RoHS standards, ensuring environmental safety.
This operational amplifier meets the AEC-Q100 automotive standard, indicating its reliability for automotive applications.
The dimensions of this operational amplifier are 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height.
This operational amplifier features two channels, making it suitable for various dual amplification applications.
The minimum operating temperature for the TLV2462CD is 0°C, allowing it to function in standard conditions.
