Tempatron 2B Series Timer Relay, 2-Contact DPDT, 110V AC, 5 to 200 s Timing, 1-Function ON Delay 2BDE200SLP110VAC

Tempatron 2BDE200SLP110VAC Timer Relay is a robust and compact solution designed for precise timing applications in industrial and electrical automation sectors. It supports a supply AC voltage of 110V AC and features a timing range adjustable from 5 to 200 seconds, making it suitable for various delay requirements. This relay employs a DPDT contact configuration with two contacts capable of switching up to 10A current, providing flexibility in controlling different circuits.

The timing adjustment is facilitated through a screwdriver slot, allowing fine time setting to meet exact application needs. The relay is mounted on an 8-pin octal base, which simplifies installation and maintenance. Its IP40 rating assures protection against solid particulates larger than 1mm, suitable for indoor environments where water exposure is minimal.

Operational temperature spans from -10°C to 60°C, ensuring reliable functioning in typical industrial and manufacturing environments. The LED indication provides clear feedback on power and relay status, enhancing operational safety and ease of monitoring.

Measuring 48 mm width, 108 mm height, and 48 mm length, the relay fits standard panels and enclosures, optimizing space usage in control systems. Manufactured under strict EN/IEC standards in the United Kingdom, this product guarantees adherence to quality and safety compliance.

Key features include a single ON Delay function and octal base for seamless integration with other system components. Typical use cases include industrial automation controls, signal conditioning in electrical panels, HVAC system control timing, and other manufacturing process automation requiring accurate timing.

Operates with a DPDT contact configuration ensuring versatile switching capability. Designed for AC voltage operation at 110V for standard industrial power supply compatibility. Punches a timing range from 5 to 200 seconds adjustable via screwdriver slot.

Rated contact current of 10A to handle moderate electrical load applications. Compact dimensions of 48 mm width, 108 mm height, and 48 mm length for panel mounting. Features an 8-pin octal base terminal for easy installation and wiring.

IP40 rated for protection against solid objects larger than 1mm but not against water. Operating temperature range between -10°C to 60°C for reliable performance in varied environments. Indicates power and relay energised status via LED for operational feedback.

Constructed in the United Kingdom adhering to EN/IEC standards for quality and safety. Explore more Timer Relays and control devices available to meet diverse industrial automation requirements at EnvMart.
