Tempatron 14-Way IDC Connector Male for Cable, 2 Row, 500V, 1A D14-EG

Free Delivery in India | Lowest Global Shipping Charges

Tempatron 14-Way IDC Connector Male for Cable, 2 Row, 500V, 1A D14-EG

Name: Tempatron 14-Way IDC Connector Male for Cable, 2 Row, 500V, 1A D14-EG
Brand: Tempatron
SKU: 139914
Price: 2.12 USD
Availability: InStock



Category IDC Connector Brand Tempatron Condition New

Specifications

Country of Origin	India
Voltage	500V
Brand	Tempatron
Orientation	Straight
Current	1A
Model	D14-EG
Mount Type	Cable
Housing Material	Polycarbonate
Contact Material	Phosphor Bronze
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.8mm
Contact Plating	Gold
Number of Contacts	14
Contact Gender	Male
Connector Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector,rectangular,IDC,DIP plug,14 way,square pinsBrand	3M
14 way IDC round gold pin DIL plugBrand	3M
3M 14-Way IDC Connector Plug for Cable Mount, 2-RowBrand	3M

Key Features

The connector features 14 contacts arranged in 2 rows for cable mating.
It has a pitch of 2.8 mm and is designed with unshrouded, straight orientation.
The contacts are gold-plated phosphor bronze, ensuring reliable conductivity and corrosion resistance.
Housing is made from black polycarbonate with UL94V-0 flammability rating for safety.
Suitable for operating temperatures ranging from -55°C to +105°C in harsh environments.
Termination type is IDC for easy and cost-effective ribbon cable termination onto PCBs.
Designed as a 2 DIL plug style with open construction to facilitate daisy chaining.
Manufactured in India and meets RoHS compliance requirements.

Product Description

Tempatron D14-EG 14-Way IDC Connector Male for Cable, 2 Row is a high-quality IDC connector designed for reliable cable-to-PCB connections. It operates at a voltage rating of 500V and supports current up to 1A, suitable for various electronic and electrical applications.

The connector hosts 14 gold-plated phosphor bronze contacts arranged in two rows with a 2.8 mm pitch, offering excellent electrical conductivity and corrosion resistance.

Its black polycarbonate housing is rated UL94V-0 for flame retardance, ensuring safe operation across a wide temperature range from -55°C to +105°C. The unshrouded and straight orientation design allows for easy mating and flexibility in application.

The IDC termination type enables cost-effective, rapid, and reliable ribbon cable termination onto printed circuit boards. The style conforms to 2 DIL plugs with an open construction, allowing daisy chaining in complex circuitry.

14 contacts in 2 rows for efficient cable connections. Gold-plated phosphor bronze contacts for durability and conductivity. Black polycarbonate housing rated UL94V-0 for enhanced safety. Voltage rating of 500V and current rating of 1A for reliable performance.

Operating temperature range from -55°C to +105°C suitable for harsh industrial conditions. IDC termination allowing quick and cost-effective ribbon cable connection to PCBs. Unshrouded, straight connector design for flexible applications.

Manufactured in India with adherence to environmental RoHS standards.

This connector is ideal for use in electronics components, power and connectors, and PCB connectors and wire housings sectors. It can be used extensively in industrial manufacturing, laboratory equipment, electronics assembly, and other specialized electronics applications.
