STMicroelectronics 4-Element Uni-Directional TVS Diode 100W Power 6-Pin SOT-23 ESDA6V1-5SC6

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics 4-Element Uni-Directional TVS Diode 100W Power 6-Pin SOT-23 ESDA6V1-5SC6

Name: STMicroelectronics 4-Element Uni-Directional TVS Diode 100W Power 6-Pin SOT-23 ESDA6V1-5SC6
Brand: STMicroelectronics
SKU: 116471



Category TVS Diode Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	1.3mm
Length	3.05mm
Model	ESDA6V1-5SC6
Width	1.75mm
Mount Type	Surface
Maximum Operating Temperature	125°C
Package Type	SOT-23
Minimum Operating Temperature	-40°C
Pin Count	6
Number of Elements per Chip	4
Diode Configuration	Common Anode
Direction Type	Uni-Directional
Minimum Breakdown Voltage Vbr	6.1V
Maximum Reverse Stand-off Voltage Vwm	3V
Peak Pulse Power Dissipation Pppm	100W
Test Current It	1mA
Maximum Reverse Leakage Current	1μA

Key Features

Designed for ESD protection with 4 elements per chip providing robust transient voltage suppression.
Features a common anode diode configuration suitable for uni-directional voltage clamping.
Minimum breakdown voltage of 6.1V and maximum reverse stand-off voltage of 3V ensure effective protection.
Compact surface-mount SOT-23 package measuring 3.05mm length, 1.75mm width, and 1.3mm height.
Operates within a temperature range of -40°C to 125°C, enhancing reliability in harsh environments.
Maximum reverse leakage current is only 1μA, ensuring minimal impact under normal conditions.
Test current rating of 1mA and absence of automotive certification specify use in general industrial and electronics applications.
Peak pulse power of 100W allows handling high transient energy surges effectively.

Product Description

STMicroelectronics ESDA6V1-5SC6 is a high-performance 4-element uni-directional transient voltage suppressor (TVS) diode designed for protecting sensitive electronic devices from voltage spikes and electrostatic discharge (ESD). Packaged in a compact 6-pin SOT-23 surface mount package, this TVS diode effectively clamps transient surges up to 100 watts peak power, safeguarding circuits in a variety of industrial and commercial electronic systems.

The diode features a common anode configuration and uni-directional operation to provide precise and reliable transient voltage protection. It has a minimum breakdown voltage of 6.1 volts and a maximum reverse stand-off voltage of 3 volts, making it ideal for low-voltage applications that require fast and effective clamp action without affecting normal circuit operation.

With an operating temperature range from -40°C to 125°C, the ESDA6V1-5SC6 ensures consistent performance in harsh environmental conditions. The extremely low maximum reverse leakage current of 1 microampere contributes to energy efficiency and reduces leakage-related noise in sensitive circuits.

The product contains 4 elements per chip to provide robust multi-point ESD protection within a single package, saving board space while enhancing protection coverage. This TVS diode is particularly suited for industrial environments, communication devices, power supplies, and electronic instrumentation where transient suppression is critical for device longevity and system reliability.

The small SOT-23 package occupies minimal PCB space with dimensions of 3.05mm (length) x 1.75mm (width) x 1.3mm (height), enabling compact and lightweight designs in modern electronic products.

Designed for electrostatic discharge protection with four clamping elements within one chip. Uni-directional diode configuration ensures precise voltage clamping for sensitive circuits. Handles peak pulse power up to 100 watts ensuring effective transient suppression.

Compact 6-pin surface mount SOT-23 package minimizes PCB footprint. Wide operating temperature range from -40°C to 125°C for demanding environments. Extremely low leakage current maintains circuit efficiency and reduces interference.

Applicable in industrial, communication, instrumentation, and power electronics fields.

Choose the STMicroelectronics ESDA6V1-5SC6 for reliable, efficient transient voltage protection in advanced electronics. Browse more high-quality TVS Diodes and semiconductor components on EnvMart to find the right parts for your designs.
