| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 0.47mm |
| Length | 1mm |
| Model | BZX8850S-C36-QYL |
| Mount Type | Surface |
| Series | BZX8850S |
| Maximum Operating Temperature | 150°C |
| Working voltage range | nominal 1.8 V to 75 V |
| Package Type | DFN1006BD-2 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 365mW |
| Diode Configuration | Single |
| Test Current It | 50μA |
| Maximum Reverse Leakage Current | 50nA |
| Nominal Zener Voltage Vz | 36V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 350Ω |
| Typical Voltage Temperature Coefficient | 30.4mV/K |
Nexperia BZX8850S-C36-QYL is a surface-mounted Zener diode specified for voltage regulation and low-current applications. It features a nominal Zener voltage of 36 V, a maximum power dissipation of 365 mW, and is packaged in a compact DFN1006BD-2 surface mount device with 2 pins. This diode ensures stable voltage regulation with a tolerance of ±5% and operates effectively at a low test current of 50 μA, making it ideal for portable battery-powered and low bias circuits.
The diode supports an operating temperature range from -55°C to 150°C, making it versatile for industrial, automotive, and commercial electronics applications. Its automotive standard compliance (AEC-Q101) confirms its suitability for demanding automotive environments. The typical voltage temperature coefficient of 30.4 mV/K helps maintain consistent voltage regulation over temperature fluctuations.
This component is well-suited for use in power supply protection, voltage reference circuits, and other semiconductor discrete applications within electronic components assemblies. The surface mount package allows for efficient integration on PCBs in electronics manufacturing, improving production efficiency and miniaturization.
Single diode configuration suitable for voltage regulation. Operates with a nominal Zener voltage of 36 V and ±5% tolerance. Surface mount package type DFN1006BD-2 with 2 pins. Test current set at 50 μA for low bias applications.
Maximum power dissipation of 365 mW for efficient thermal performance. Maximum reverse leakage current is 50 nA ensuring low leakage losses. Operating temperature range from -55°C to +150°C for reliability. Automotive compliant with AEC-Q101 standard.
Typical voltage temperature coefficient of 30.4 mV/K for stable operation.
EnvMart offers this Nexperia Zener diode as part of its electronics components range, ideal for engineers and manufacturers requiring reliable voltage regulation devices meeting automotive standards.
