Wurth Elektronik WR-PHD Series Bottom Entry Through Hole PCB Socket, 4-Contact, 2 Row, 2.54 mm Pitch, Gold 61300425721

Name: Wurth Elektronik WR-PHD Series Bottom Entry Through Hole PCB Socket, 4-Contact, 2 Row, 2.54 mm Pitch, Gold 61300425721
Brand: Wurth Elektronik
SKU: 112346
Price: 1.14 USD
Availability: InStock



Category PCB Socket Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	500V
Brand	Wurth Elektronik
Orientation	Bottom Entry
Current	3A
Mount Type	Through Hole
Contact Material	Copper Alloy
Series	WR-PHD
Durability	25mating cycles
Termination Type	Solder
Maximum Operating Temperature	105°C
Sub Type	PCB Socket
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	2.54mm
Standards/Approvals	RoHS
Contact Plating	Gold
Number of Contacts	4
Connector System	Board-to-Board

Key Features

This PCB socket features gold-plated copper alloy contacts for reliable conductivity.
Designed for a current rating of 3 amperes and voltage of 500 volts.
Its insulating body is made from Nylon 9T, with UL94 V-0 flammability rating ensuring fire safety.
Supports operation within a temperature range of -40°C to +105°C.
The socket is through-hole mounted with bottom entry orientation for robust mechanical and electrical connection.
It offers durability up to 25 mating cycles for multiple insertions.
It complies with RoHS standards for environmental safety.
Manufactured in Taiwan, Province Of China.

Product Description

Wurth Elektronik 61300425721 Bottom Entry Through Hole PCB Socket is a high-quality 4-contact, 2-row connector designed for electronic components requiring a 2.54 mm pitch solder mounting with sturdy board-to-board connection.

This socket features contacts made of copper alloy plated with gold, providing excellent electrical conductivity and corrosion resistance. The insulator is manufactured using Nylon 9T, selected for its UL94 V-0 flammability rating, ensuring safety in industrial, industrial automation, and electronics manufacturing uses.

Operating reliably between -40°C and 105°C, this socket is suitable for demanding electronic applications that require stable electrical and mechanical performance over a wide temperature range. Its through-hole mount type with bottom entry orientation enables secure mechanical stability on PCBs.

The product supports a maximum current of 3 amperes and voltage up to 500 volts, suitable for most low power electronic applications. It is RoHS compliant, making it environmentally friendly and compliant with international hazardous substances regulations.

This PCB socket incorporates gold-plated copper alloy contacts for enhanced durability and low signal loss. Designed to sustain up to 25 mating cycles, suitable for repeated assembly or maintenance. The Nylon 9T insulator ensures electrical isolation and excellent thermal resistance.

Standard 2.54 mm pitch and 2 row layout facilitate compatibility with industry-standard PCB connectors. Bottom entry orientation supports compact PCB designs and ease of soldering. Ideal for applications in electronics manufacturing, industrial control systems, and embedded device assembly.

Manufactured in Taiwan, Province Of China, ensuring quality control and reliability.

This Wurth Elektronik PCB Socket is part of the WR-PHD series, trusted for its robust performance in demanding industrial and commercial electronics environments. It is especially suited for applications requiring secure, reliable low-current connections on printed circuit boards.
