Weidmüller LSF Series PCB Terminal Block 4-Contact 5 mm Pitch 1 Row 500V 17.5A 1825980000
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 500V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | 180° |
| Current | 17.5A |
| Depth | 7.8mm |
| Width | 19.2mm |
| Housing Material | Liquid Crystal Polymer Fibreglass |
| Series | LSF |
| Number of Rows | 1 |
| Pitch | 5mm |
| Standards/Approvals | RoHS conform |
| Number of Contacts | 4 |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Push-in |
Key Features
- Equipped with four contact points for secure electrical connections.
- Constructed from liquid crystal polymer fibreglass for durability.
- Operates with push-in wire connection method for easy installation.
- Compatible with wire sizes from 0.2 to 1.5 mm² (28 to 14 AWG).
- Designed for a 180° orientation in black color.
- Optimized for automatic assembly and reflow soldering (SMT) processes.
- Compact size with a width of 19.2 mm and depth of 7.8 mm.
- Complies with RoHS standards for environmental safety.
Product Description
Weidmüller 1825980000 LSF Series PCB Terminal Block is engineered for industrial and electronic applications requiring reliable and efficient connections. It features a 4-contact design with a 5 mm pitch and a single row assembly, rated for 500 volts and 17.5 amps. The terminal block uses a push-in wire connection method allowing for tool-free insertion and removal of solid wires or wires fitted with ferrules. Its housing is made from liquid crystal polymer fibreglass, providing robust mechanical strength and thermal resistance suitable for automatic SMT reflow soldering.
The compact dimensions of 19.2 mm width and 7.8 mm depth support multi-layer PCB designs while optimizing space. This terminal block supports wire sizes from 0.2 mm² up to 1.5 mm² (28 to 14 AWG), making it versatile for various wiring needs. The 180° orientation and black color ensure convenient and clear installation layouts, with potentials and clamping points marked by colored push buttons.
This product is ideal for use in industrial automation, power control, instrumentation, and communication devices. It meets RoHS environmental directives, ensuring compliance with hazardous substance restrictions. The LSF series design supports automated assembly and reliability in manufacturing processes.
Equipped with four contact points for secure electrical connections. Constructed from liquid crystal polymer fibreglass for durability. Operates with push-in wire connection method for easy installation. Compatible with wire sizes from 0.2 to 1.5 mm² (28 to 14 AWG).
Designed for a 180° orientation in black color. Optimized for automatic assembly and reflow soldering (SMT) processes. Compact size with a width of 19.2 mm and depth of 7.8 mm. Complies with RoHS standards for environmental safety.
Explore more electronic components and PCB Terminal Blocks in the Electronics & Electricals category at EnvMart for your industrial and commercial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block is rated for 500 volts and 17.5 amps, making it suitable for various industrial applications.
It is compatible with wire sizes ranging from 0.2 mm² to 1.5 mm² (28 to 14 AWG), allowing for versatile wiring options.
This model employs a push-in wire connection method, which allows for tool-free insertion and removal of wires.
The dimensions of this terminal block are 19.2 mm in width and 7.8 mm in depth, making it compact for multi-layer PCB designs.
Yes, it complies with RoHS standards, ensuring it meets environmental safety requirements regarding hazardous substances.
The housing is constructed from liquid crystal polymer fibreglass, providing mechanical strength and thermal resistance.
This terminal block features four contact points, ensuring secure electrical connections.
It is designed for a 180° orientation, which aids in clear installation layouts.
This model is part of the LSF Series, which is optimized for automatic assembly and reflow soldering processes.
The pitch of this terminal block is 5 mm, suitable for various PCB applications.
This terminal block is manufactured in India, contributing to its availability in the market.
