Abracon 20 MHz Crystal ±30 ppm Surface Mount 4-Pin 0.55 mm Height 2 mm Length 1.6 mm Width FC1BACBEI20.0-T3

Abracon FC1BACBEI20.0-T3 is a precision 20 MHz crystal designed for surface mount applications requiring a compact 4-pin configuration. With a frequency tolerance of ±30 ppm and frequency stability of ±50 ppm, it ensures reliable and accurate oscillation in demanding industrial and automotive electronic circuits.

This crystal's dimensions of 2 mm length, 1.6 mm width, and 0.55 mm height enable efficient PCB space utilization. The load capacitance is 10 pF with a shunt capacitance of 3 pF, tailored for high-frequency performance.

Engineered to operate from -40°C up to +125°C, it is compliant with RoHS environmental standards and qualified under the automotive AEC-Q200 standard, confirming its robustness for automotive and industrial environments.

Provided in tape and reel packaging, it supports automated pick-and-place manufacturing processes, enhancing production efficiency in electronics manufacturing. This crystal operates at a standard frequency of 20 MHz. Surface mount package with 4 pins for reliable PCB mounting.

Compact dimensions: 2 mm length, 1.6 mm width, 0.55 mm height. Frequency tolerance ±30 ppm and stability ±50 ppm. Operating temperature from -40°C to +125°C ensures durability. RoHS compliant and AEC-Q200 automotive qualified for stringent quality assurance.

Tape and reel packaging for streamlined component handling. Low shunt capacitance of approximately 3 pF optimizes circuit design.

This product is ideal for use in industrial, automotive, consumer electronics, communications equipment, and precision oscillator designs. For comprehensive product selection, please explore the Crystal Units category at EnvMart.
