Samtec Straight Through Hole PCB Socket 5-Contact 1 Row 2.54 mm Pitch Solder SL-105-G-11
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Model | SL-105-G-11 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Beryllium Copper Alloy, Brass |
| Series | SL |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Machine Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Constructed with black Liquid Crystal Polymer housing for excellent durability.
- Designed for through-hole mounting and straight orientation.
- Contact material consists of beryllium copper alloy and brass for reliable conductivity.
- Contacts are gold plated to ensure effective corrosion resistance and signal integrity.
- Operates reliably within a temperature range of -55°C to 125°C.
- Compatible with board-to-board connector systems for versatile PCB applications.
- Complies with RoHS standards for environmental safety.
- Female contact gender suitable for mating with corresponding male connectors.
Product Description
The Samtec SL-105-G-11 is a high-quality straight through hole PCB socket designed for industrial and electronic component applications. It features 5 contacts arranged in a single row with a precise 2.54 mm pitch making it ideal for board-to-board connector systems. The housing is made from black Liquid Crystal Polymer (LCP), providing excellent mechanical strength and thermal stability.
Its through-hole mount type and straight orientation enables reliable solder termination on printed circuit boards. The contact parts are fabricated from a beryllium copper alloy and brass, which are plated with gold to enhance conductivity and resist corrosion under demanding operating conditions.
This PCB socket supports operating temperatures ranging from -55°C to 125°C, catering to various industrial environments including electronics manufacturing, telecommunications, and automation systems.
Black Liquid Crystal Polymer housing ensures mechanical robustness. Beryllium copper alloy and brass contacts with gold plating improve electrical performance. Designed for through-hole solder mounting on PCB boards. Single row configuration with 5 female contacts at 2.54 mm pitch.
RoHS compliant for environmentally friendly use. Suitable for board-to-board connectivity in electronic assemblies. Temperature rating supports extreme industrial applications.
This product is widely used in manufacturing, industrial electronics, telecommunications, and automotive electronics for secure and reliable PCB connections. The Samtec SL series sockets are well-regarded in engineering and production for their precision and endurance.
Explore more products in the PCB Sockets category on EnvMart to find complementary components and accessories for your electronic design projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this PCB socket is 2.54 mm, which is standard for many board-to-board connector systems.
The contacts are made from a beryllium copper alloy and brass, and they are gold plated to enhance conductivity and corrosion resistance.
It operates reliably within a temperature range of -55°C to 125°C, making it suitable for various industrial applications.
This model features 5 contacts arranged in a single row, designed for through-hole mounting.
Yes, it complies with RoHS standards, ensuring it meets environmental safety requirements.
This model uses through-hole mounting, which allows for reliable solder termination on printed circuit boards.
The orientation of this socket is straight, which facilitates easy installation on PCBs.
The housing is constructed from black Liquid Crystal Polymer, providing excellent mechanical strength and thermal stability.
It is compatible with board-to-board connector systems, making it versatile for various PCB applications.
The termination type for this PCB socket is solder, which is standard for through-hole components.
This product is manufactured in India, ensuring it meets specific production standards.
It is widely used in manufacturing, industrial electronics, telecommunications, and automotive electronics for secure PCB connections.
