Samtec QTH Series Right Angle Surface PCB Header 60 Contacts 0.5mm Pitch 2 Row Shrouded QTH-030-03-F-D-A-K-TR

Name: Samtec QTH Series Right Angle Surface PCB Header 60 Contacts 0.5mm Pitch 2 Row Shrouded QTH-030-03-F-D-A-K-TR
Brand: Samtec
SKU: 108754
Price: 9.34 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	220V
Brand	Samtec
Orientation	Right Angle
Current	2.2A
Model	QTH-030-03-F-D-A-K-TR
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	QTH
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	0.5mm
Contact Plating	Gold or Tin
Number of Contacts	60
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board

Key Features

The connector supports a current rating of 2.2 A.
It features a liquid crystal polymer housing for durability.
The contact material is phosphor bronze with gold or tin plating for reliable conductivity.
Configured with 2 rows and right angle orientation for compact PCB layouts.
Minimum operating temperature reaches -55°C and maximum up to 125°C.
This model includes a board guide and ground bus for stable connections.
Termination type is solder suitable for surface mount technology.
Ideal for industrial electronics requiring dependable, high-density interconnects.

Product Description

Samtec QTH-030-03-F-D-A-K-TR is a high-performance QTH Series right angle surface mount PCB header connector with 60 contacts arranged in 2 rows at a fine 0.5 mm pitch, designed for board-to-board connector systems.

The connector housing is constructed from liquid crystal polymer, offering excellent mechanical resilience and thermal stability, suitable for operating temperatures ranging from -55°C to 125°C. The male contacts are made of phosphor bronze and plated with gold or tin to ensure robust electrical performance and long service life.

This shrouded connector includes features such as a board guide and ground bus plane, enhancing connection integrity and alignment during assembly. It utilizes solder termination type designed for surface mounting on PCBs, facilitating automated pick and place assembly processes.

Rated for a current of 2.2 amperes and voltage of 220 volts, this PCB header is well suited for a variety of industrial electronics and equipment applications, including telecommunication, computing, instrumentation, and embedded systems requiring compact and reliable interconnection solutions.

The connector supports a current rating of 2.2 A. It features a liquid crystal polymer housing for durability. The contact material is phosphor bronze with gold or tin plating for reliable conductivity. Configured with 2 rows and right angle orientation for compact PCB layouts.

Minimum operating temperature reaches -55°C and maximum up to 125°C. This model includes a board guide and ground bus for stable connections. Termination type is solder suitable for surface mount technology. Ideal for industrial electronics requiring dependable, high-density interconnects.

For professionals seeking quality PCB Headers with precise pitch and mounting features, the Samtec QTH-030-03-F-D-A-K-TR offers an excellent solution. Browse more connectors and PCB components in our Electronics & Electricals category for complete system integration.
