Samtec PCB Socket Right Angle Through Hole Board-to-Board Connector 5-Contact 1 Row 2.54 mm Pitch 6.3A SSQ-105-02-T-S-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 655V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 6.3A |
| Model | SSQ-105-02-T-S-RA |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | SSQ |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 5 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- The socket features low insertion force contacts with square tails for self-nesting application.
- Constructed with a black liquid crystal polymer housing providing durability and high insulation.
- Phosphor bronze female contacts are plated with tin ensuring reliable electrical connectivity.
- Rated for 6.3 A current and 655 V voltage making it suitable for demanding electronic applications.
- Designed to operate across a wide temperature range from -55°C to 105°C.
- Series SSQ connectors ensure compatibility and modular design flexibility on PCBs.
- Right angle orientation facilitates efficient board layout in compact electronic assemblies.
- The socket system provides board-to-board connection with stable mechanical and electrical performance.
Product Description
Samtec SSQ-105-02-T-S-RA PCB Socket is a high-quality, right angle through hole solder termination board-to-board connector designed for electronics and electrical assemblies. This connector features a 5-contact, 1-row socket strip with a 2.54 mm pitch, ideal for compact PCB applications requiring reliable electrical connections.
The housing is made of black liquid crystal polymer which offers excellent mechanical strength and electrical insulation. The phosphor bronze female contacts are plated with matte tin, providing corrosion resistance and stable conductivity. The socket incorporates a low insertion force contact design with a 0.635 mm square tail, enabling efficient assembly and nesting.
Electrical ratings include a current capacity of 6.3 A and voltage ratings of 465 VAC and 655 VDC, supporting diverse power and signal needs. Operating temperature ranges from -55°C to 105°C, allowing usage in harsh environmental conditions.
The SSQ series is intended for board-to-board connections with right angle orientation, optimizing PCB real estate and assembly layout. This connector supports robust mechanical and electrical interfaces and fits a wide range of industrial, electronic manufacturing, laboratory instrumentation, and telecommunications applications.
The socket's low insertion force contacts reduce wear and facilitate repeated mating cycles. The liquid crystal polymer housing provides high durability and electrical isolation. Phosphor bronze contacts with tin plating enhance signal integrity and longevity.
Rated for 6.3 A current and 655 V voltage to meet power and signal requirements. Designed for operating temperatures from -55°C up to 105°C to ensure reliability. Right angle, through hole mounting streamlines PCB design and assembly.
Five contacts in a single row with 2.54 mm pitch for precise board connections.
This socket is a key component in the assembly of industrial electronic devices, ensuring connection stability under demanding conditions. It is suitable for applications in manufacturing, laboratory setups, power distribution systems, and telecommunications gear where board-to-board connections are essential.
Explore the range of PCB connectors and sockets at EnvMart for comprehensive industrial and electronic component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SSQ-105-02-T-S-RA connector has a current rating of 6.3 A.
This model is rated for a voltage of 655 V.
The contacts in this connector have a pitch of 2.54 mm.
The housing is made from liquid crystal polymer, while the contacts are phosphor bronze plated with tin.
It operates within a temperature range of -55°C to 105°C.
This connector features 5 contacts in a single row.
The connector uses through hole mounting for installation.
It is a board-to-board connector system.
The orientation of this socket is right angle, which helps in compact PCB layouts.
The termination type for this connector is solder.
This connector is suitable for applications in industrial electronic devices, laboratory setups, and telecommunications gear.
The contact gender of the SSQ-105-02-T-S-RA is female.
