Samtec SSQ Series Straight Through Hole PCB Socket 26-Contact 2 Row 2.54 mm Pitch Solder SSQ-113-03-T-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 655V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 6.3A |
| Model | SSQ-113-03-T-D |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | SSQ |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 26 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Row Pitch | 2.5mm |
Key Features
- Constructed with a liquid crystal polymer housing for durability.
- Phosphor bronze contacts with tin plating ensure reliable electrical connection.
- Rated for a current of 6.3 A and voltage up to 655 V for versatile applications.
- Designed for through-hole mounting and straight orientation for board-to-board connections.
- Operates within a temperature range of -55°C to 105°C for industrial reliability.
- Square tail contacts measuring 0.025" (0.635 mm) enable self-nesting and easy soldering.
- The 2.5 mm row pitch and 2 rows configuration optimize contact spacing.
- Suitable for industrial, electronic, and manufacturing PCB socket applications.
Product Description
Samtec SSQ-113-03-T-D is a high-quality straight through hole PCB socket designed for robust board-to-board electrical connections. It features 26 female contacts arranged in 2 rows with a 2.54 mm pitch, making it suitable for precision electronic assemblies.
The housing is made of durable liquid crystal polymer, providing excellent insulation and mechanical strength. Contacts are fabricated from phosphor bronze and plated with matte tin to ensure long-term conductivity and corrosion resistance.
The socket supports a current rating of 6.3 A and a voltage rating of 655 V (AC and DC), accommodating demanding power requirements. Its through-hole mount type and straight orientation facilitate straightforward PCB integration.
Operational temperature ranges from -55°C up to 105°C, enabling reliable performance in diverse industrial and manufacturing environments. The square tail design of contacts (.025" or 0.635 mm) supports self-nesting and low insertion force solder applications, improving assembly efficiency.
This product is ideal for use in electronics manufacturing, industrial control equipment, and other applications that require secure and durable PCB socket connections. Durable liquid crystal polymer housing ensures insulation and toughness.
Phosphor bronze contacts with tin plating enhance electrical performance. High current and voltage ratings provide versatility in PCB design. Through-hole mount and straight orientation for easy assembly. Wide temperature operating range for industrial applications.
Square tail contacts enable efficient soldering and reliable connections. Standard 2.54 mm pitch and 2-row configuration for compatibility. Designed for board-to-board connector systems in demanding environments. This Samtec PCB socket is a dependable component in electronic component assemblies and industrial tools.
Explore more PCB Sockets and related components in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 6.3 A and a voltage of up to 655 V, making it suitable for various applications.
The socket features a 2.54 mm pitch and is configured with 26 female contacts arranged in 2 rows.
The housing is made from liquid crystal polymer, while the contacts are fabricated from phosphor bronze and plated with tin for enhanced conductivity.
It operates within a temperature range of -55°C to 105°C, suitable for industrial environments.
This model is designed for through-hole mounting, facilitating straightforward PCB integration.
It uses a solder termination type for secure connections during assembly.
The contacts are oriented straight, allowing for easy board-to-board connections.
This model is designed for a board-to-board connector system, making it suitable for various electronic assemblies.
The square tail design of the contacts enables self-nesting and low insertion force solder applications, improving assembly efficiency.
The tin plating on the phosphor bronze contacts enhances electrical performance and provides corrosion resistance.
The country of origin for this PCB socket is India.
It is ideal for use in electronics manufacturing, industrial control equipment, and other applications requiring secure PCB connections.
