Wurth Elektronik WR-PHD Series Straight Surface Mount 40-Contact 2 Row PCB Socket 61004021821
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Surface |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 105°C |
| Sub Type | SMT Female Dual Row Socket |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Contact Plating | Gold |
| Number of Contacts | 40 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Constructed with black UL94-V0 Polybutylene Terephthalate housing.
- Gold-plated copper alloy contacts provide excellent conductivity and corrosion resistance.
- Rated for 3 Amperes current and 500 Volts voltage.
- Dual row SMT female socket with a 2.54mm pitch for precise component placement.
- Operates reliably in temperatures ranging from -40°C to 105°C.
- Designed for board-to-board connector system with surface mount termination.
- Contact gender is female, suitable for high-density PCB assemblies.
- Ideal for industrial, electronic manufacturing, and power connector applications.
Product Description
Wurth Elektronik 61004021821 WR-PHD Series PCB Socket is a highly reliable straight surface mount component designed for demanding electronic and industrial applications. Featuring 40 contacts arranged in 2 rows with a 2.54mm pitch, it ensures secure and efficient board-to-board connectivity.
The socket housing is made from black Polybutylene Terephthalate (PBT) rated UL94-V0 for flame retardance, enhancing safety in electrical assemblies. Contacts are composed of copper alloy with gold plating to provide outstanding electrical conductivity and corrosion resistance, ensuring long service life.
This component supports a continuous current of up to 3A and a voltage rating of 500V, making it suitable for various power and signal applications. Its surface mount termination allows for easy placement on PCB surfaces, enhancing manufacturing efficiency.
Operating temperature ranges from -40°C to 105°C, enabling its use in diverse environmental conditions across industrial, laboratory, and manufacturing sectors. The connector system is designed specifically for board-to-board applications, with female contact gender to fit corresponding male headers.
Black UL94-V0 PBT housing provides flame resistance. Gold plated copper alloy contacts ensure reliable electrical performance. Supports 3A current and 500V voltage for diverse applications. Dual row, 40-contact layout with 2.54mm pitch for precision.
Surface mount termination facilitates PCB assembly. Wide operating temperature range of -40°C to 105°C. Female contacts ideal for mating with male header pins. Designed for industrial, electronic, and power connector systems.
This PCB socket is manufactured in Taiwan and is part of the Wurth Elektronik WR-PHD series, known for quality and durability in electronic components. It suits applications in electronics manufacturing, power supply modules, signal transmission, and board interconnect systems.
Explore more of the Wurth Elektronik PCB Socket series and related connector products at EnvMart for all your industrial and electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this model is 500 Volts, making it suitable for various power and signal applications.
It supports a continuous current of up to 3 Amperes, ensuring reliable performance in electrical connections.
The housing is made from black Polybutylene Terephthalate (PBT) rated UL94-V0, and the contacts are composed of gold-plated copper alloy for excellent conductivity and corrosion resistance.
It operates reliably in temperatures ranging from -40°C to 105°C, suitable for diverse environmental conditions.
This PCB socket features 40 contacts arranged in 2 rows, designed for efficient board-to-board connectivity.
It utilizes surface mount termination, allowing for easy placement on PCB surfaces during assembly.
The contact gender is female, designed to mate with corresponding male header pins in board-to-board applications.
This model is manufactured in Taiwan, ensuring quality in its construction.
The contacts have a pitch size of 2.54mm, allowing for precise component placement on the PCB.
It is ideal for industrial, electronic manufacturing, and power connector applications, particularly in board-to-board connectivity.
This socket is part of the Wurth Elektronik WR-PHD series, known for its reliability in electronic components.
It is designed for a board-to-board connector system, facilitating efficient interconnections between PCBs.
