Nexperia 1.15 V Zener Diode Single 300 mW 2% Tolerance Surface Mount 2-Pin SOD-323 BZX384-B15

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 1.15 V Zener Diode Single 300 mW 2% Tolerance Surface Mount 2-Pin SOD-323 BZX384-B15

Name: Nexperia 1.15 V Zener Diode Single 300 mW 2% Tolerance Surface Mount 2-Pin SOD-323 BZX384-B15
Brand: Nexperia
SKU: 107384
Price: 0.04 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.1mm
Length	2.7mm
Model	BZX384-B15
Mount Type	Surface
Series	BZX384
Maximum Operating Temperature	150°C
Package Type	SOD-323
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	300mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	15V
Zener Type	Voltage Regulator
Maximum Zener Impedance	30Ω
Typical Voltage Temperature Coefficient	11.4mV/K
Surface Mount case	SOD-323 (SC-76)
onsemi 1, 15 V Zener Diode, Single 300 mW 2 % Surface 2-Pin SOD-323Brand	onsemi

Key Features

The diode is designed for surface mount applications with a compact 2-pin SOD-323 package.
It can dissipate a maximum power of 300 mW, suitable for low-power circuits.
Operates efficiently with a test current of 5 mA and has a maximum zener impedance of 30 ohms.
Has a maximum reverse leakage current of 50 nA ensuring low leakage loss.
Supports a wide operating temperature range from -65°C to 150°C for reliability in varied conditions.
Complies with automotive standard AEC-Q101, making it suitable for automotive electronics.
Manufactured in China by Nexperia as part of the BZX384 series with stable voltage temperature coefficient of 11.4 mV/K.

Product Description

Nexperia BZX384-B15 is a high-quality 1.15 V single-element Zener diode designed as a voltage regulator with a 2% voltage tolerance. It delivers reliable performance in surface mount electronic applications with a compact 2-pin SOD-323 package.

This diode supports a maximum power dissipation of 300 mW and operates optimally at a test current of 5 mA. Its low maximum zener impedance of 30 Ω and minimal reverse leakage current of 50 nA make it highly efficient for voltage regulation tasks. The device is capable of functioning consistently over an extended operating temperature range from -65°C to +150°C, enhancing durability in industrial, automotive, and consumer electronics.

The compact package dimensions of 1.1 mm height and 2.7 mm length facilitate space constraints in circuit boards. It meets the stringent automotive standard AEC-Q101, which certifies it for use in automotive electronic systems.

This product is manufactured in China under the BZX384 series by Nexperia, a recognized semiconductor brand. The diode also features a typical voltage temperature coefficient of 11.4 mV/K for steady operation under temperature variations.

The diode configuration is single. It utilizes a surface mount technique for assembly. The pin count is 2 for connectivity. The package type is SOD-323 (SC-76). This product is compliant with automotive grade standards.

Suitable for industrial electronics, automotive controls, power supplies, and electronic testing applications, this Zener diode from Nexperia guarantees performance and reliability. Explore more semiconductor components and voltage regulation solutions at EnvMart.
