Wurth Elektronik WR-FPC Series Horizontal Surface PCB Header, 4 Contact(s), 1 mm Pitch, 1 Row, Shrouded 686104188622
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 125V |
| Brand | Wurth Elektronik |
| Orientation | Horizontal |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | WR-FPC |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Contact Type | Stamped |
| Minimum Operating Temperature | -25°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Standards/Approvals | RoHS |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 4 |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- The header supports a current rating of 1A for reliable electrical performance.
- It has a Pitch of 1 mm with a single row and 4 contact points.
- Housing material is Liquid Crystal Polymer, providing high durability and resistance.
- Phosphor Bronze contact material with tin over nickel plating ensures excellent conductivity.
- Designed for surface mount mounting with shrouded feature for secure connections.
- Operating temperature ranges from -25°C to 85°C.
- Suitable for wire-to-board connector systems in electronic assemblies.
Product Description
Wurth Elektronik 686104188622 WR-FPC Series horizontal surface PCB header is engineered with four contacts arranged in a single row with a 1 mm pitch, allowing precise wire-to-board connectivity. This shrouded header features a durable Liquid Crystal Polymer housing to provide both mechanical strength and thermal stability.
The contacts are made of phosphor bronze with tin over nickel plating, providing excellent electrical conductivity and corrosion resistance. Rated for 1A current and a voltage of 125V AC, it offers robust performance for compact electronic applications.
Its surface mount termination type via solder tabs enables reliable and streamlined PCB assembly, and the device operates efficiently across a wide temperature range from -25°C to 85°C, making it suitable for industrial and commercial electronic environments.
This product complies with RoHS standards, reflecting a lead-free and environmentally responsible design. Its stamped contact type and horizontal orientation make it an optimal choice for high-density and space-constrained PCB layouts.
The header supports a current rating of 1A for reliable electrical performance. It has a Pitch of 1 mm with a single row and 4 contact points. Housing material is Liquid Crystal Polymer, providing high durability and resistance.
Phosphor Bronze contact material with tin over nickel plating ensures excellent conductivity. Designed for surface mount mounting with shrouded feature for secure connections. Operating temperature ranges from -25°C to 85°C.
Suitable for wire-to-board connector systems in electronic assemblies. Voltage rating of 125V AC ensures safe operation.
This PCB Header is ideal for electronic manufacturing, assembly, and repair sectors where compact, reliable connectors are required. It finds application in communications, industrial controls, computing equipment, and instrumentation.
Explore more high-quality PCB connectors and electronic components at EnvMart to meet your precise engineering needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a current rating of 1A, ensuring reliable electrical performance for various applications.
The voltage rating for this model is 125V AC, allowing it to operate safely in electronic applications.
The housing is made of Liquid Crystal Polymer, while the contacts are constructed from phosphor bronze with tin over nickel plating, providing excellent conductivity and corrosion resistance.
The contacts in this header are arranged with a pitch of 1 mm, suitable for precise wire-to-board connections.
This PCB header operates efficiently within a temperature range of -25°C to 85°C, making it suitable for various environments.
This model features four contacts arranged in a single row, designed for effective connectivity.
It utilizes a solder termination type, allowing for reliable surface mount assembly on PCBs.
Yes, this product complies with RoHS standards, reflecting a lead-free and environmentally responsible design.
This model is designed for wire-to-board connector systems, making it suitable for various electronic assemblies.
The orientation of this PCB header is horizontal, which is optimal for high-density PCB layouts.
The contact type for this header is stamped, which contributes to its compact design and efficient electrical performance.
The country of origin for this PCB header is China, indicating its manufacturing location.
