Schurter FMBB RAIL 3A 250V AC 50Hz 60Hz DIN Rail Mount RFI Filter Screw Termination 1 Phase 5500.2265

Free Delivery in India | Lowest Global Shipping Charges

Schurter FMBB RAIL 3A 250V AC 50Hz 60Hz DIN Rail Mount RFI Filter Screw Termination 1 Phase 5500.2265

Name: Schurter FMBB RAIL 3A 250V AC 50Hz 60Hz DIN Rail Mount RFI Filter Screw Termination 1 Phase 5500.2265
Brand: Schurter
SKU: 105853



Category Power Line Filters Brand Schurter Condition New

Specifications

Country of Origin	India
Brand	Schurter
Height	48mm
Length	102mm
Depth	61mm
Mount Type	DIN Rail
Operating Frequency	50, 60Hz
Series	FMBB RAIL
Maximum Operating Temperature	100°C
Number Of Stages	2
Resistance	1mΩ
Capacitance	680nF
Minimum Operating Temperature	-25°C
Maximum Current	3A
Number of Phases	1
Leakage Current	250μA
Maximum Voltage	250V ac
Inductance	2mH
Standards/Approvals	EN 60950
Termination Style	Screw

Key Features

Designed for industrial electric switch and control cabinets.
Two-stage single-phase broadband attenuation filter with screw termination.
Effective against symmetrical and asymmetrical interference from 10kHz to 30MHz frequency range.
Compact metal housing with DIN rail mount for easy installation.
Compliance to EN 60950 safety standard ensures reliable operation.
Operating temperature range from -25°C to 100°C.
Features 680nF capacitance and 2mH inductance for noise suppression.
Leakage current limited to 250μA for safety and performance.

Product Description

Schurter 5500.2265 FMBB RAIL series is a DIN rail mounted RFI filter designed for industrial applications, including electric switch and control cabinets. Rated for a maximum current of 3A and maximum voltage of 250V AC, it operates efficiently at 50Hz and 60Hz frequencies.

The filter utilizes a two-stage single-phase broadband attenuation design to suppress interference effectively within the 10kHz to 30MHz range. Its screw termination style and metal housing ensure robust and secure mounting on standard DIN rails.

With a capacitance of 680nF and inductance of 2mH, the filter minimizes symmetrical and asymmetrical noise, enhancing system reliability and electromagnetic compatibility. Safety is certified to EN 60950 standards, suitable for industrial and commercial electrical equipment.

Operating temperature ranges between -25°C and 100°C, supporting sustained performance in demanding environments. Leakage current remains low at 250μA, maintaining operational safety.

Physical dimensions include 102mm length, 61mm depth, and 48mm height, fitting within compact electrical panel setups. The filter’s resistance is 1mΩ, contributing to minimal power loss.

Designed for industrial electric switch and control cabinets. Two-stage broadband attenuation filter for EMI/RFI suppression. DIN rail mount with screw termination for secure installation. Effective noise reduction from 10kHz to 30MHz frequency range.

Compliance with EN 60950 safety standards. Capacitance 680nF and inductance 2mH for effective filtering. Operating temperature range -25°C to 100°C. Leakage current limited to 250μA. Dimension: 102mm x 61mm x 48mm. Resistance of 1mΩ minimizes power loss.

This Schurter FMBB RAIL RFI filter is ideal for improving electromagnetic compatibility in industrial controls and power electronics. Browse EnvMart for more Schurter electronic components and power line filter solutions.
