TRACOPOWER High-Efficiency 30W DC/DC Converter, 24V DC Output, 1.25A, 36-75V DC Input, PCB Mount THN 30-4815
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER THN 30 DC/DC Converter, 24V dc/ 1 |
| Brand | TRACOPOWER |
| Efficiency | 91% |
| Length | 25.4mm |
| Model | THN 30-4815 |
| Depth | 9.9mm |
| Mount Type | PCB |
| Series | THN 30 |
| Maximum Operating Temperature | 80°C |
| Package Type | Shielded Metal Case with Isolated Baseplate |
| Minimum Operating Temperature | -40°C |
| MTBF | 1300000h |
| Number of outputs | 1 |
| Maximum Output Power | 30W |
| Maximum Input Voltage | 75V dc |
| Minimum Input Voltage | 36V |
| Number of Pins | 6 |
| Output Voltage 1 | 24V dc |
| Output Current 1 | 1.25A |
| Isolation Voltage | 1.5kV dc |
| Input Ratio | 2:1 |
| Input Ratio 2 | 1 |
| Wide 2 | 1 input voltage range |
Key Features
- High-efficiency converter achieving 91% efficiency across load ranges.
- Compact shielded metal case with isolated baseplate ensures durability.
- Wide operating temperature range from -40°C to +80°C suitable for diverse environments.
- 2:1 input voltage ratio supports reliable operation under varying supply voltages.
- Offers output voltage adjustment range of -10% to +10% for precise regulation.
- Single output design with 1.5kV DC isolation voltage enhances safety.
- Low no-load current design ideal for battery-operated systems.
- Remote On/Off control feature for flexible operation management.
Product Description
TRACOPOWER THN 30-4815 is a high-performance 30W DC/DC converter designed for PCB mounting. It provides a regulated 24V DC output at 1.25A with a wide input voltage range from 36V to 75V DC, making it suitable for various power supply configurations. The shielded metal case with an isolated baseplate offers robust protection and reduces electromagnetic interference.
This converter operates efficiently with a 91% efficiency rating and delivers reliable output voltage regulation with an adjustment range of ±10%. Its wide operating temperature range from -40°C to +80°C allows use in harsh industrial environments. The device features remote On/Off control and a low no-load input current, making it especially suited for battery-powered applications.
Isolation voltage of 1.5kV DC protects sensitive equipment, and the unit has a MTBF of 1.3 million hours, ensuring superior durability and reliability over long operational periods. The compact dimensions (25.4mm length, 9.9mm depth) allow easy integration in space-constrained PCB layouts.
Typical industrial applications include mobile equipment, instrumentation, distributed power architectures in communications, and industrial electronics where compact, high-efficiency isolated DC/DC conversion is essential. The converter complies with safety standards UL/cUL 60950-1 and IEC/EN 60950-1. It is manufactured in Taiwan, Province Of China.
High-efficiency 30W power density converter. Compact metal case with isolated baseplate. Wide 36 - 75V DC input voltage range with 2:1 ratio. Output voltage adjustable within ±10% range. Single output with 1.5kV DC isolation voltage.
Operating temperature from -40°C up to 80°C, 85°C with heatsink. Low input current at no load and remote On/Off control. MTBF rating exceeding 1,300,000 hours. Ideal for mobile, industrial, and communications equipment. Compliance with UL/cUL and IEC/EN 60950-1 standards.
Explore the range of DC/DC Converters at EnvMart for versatile power supply solutions tailored to demanding industrial and electronic applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a regulated output voltage of 24V DC with a maximum output current of 1.25A.
It operates with a wide input voltage range from 36V to 75V DC, supporting a 2:1 input voltage ratio.
The converter achieves an efficiency of 91% across load ranges, ensuring effective power conversion.
This unit has compact dimensions of 25.4mm in length and 9.9mm in depth, making it suitable for space-constrained PCB layouts.
It features an isolation voltage of 1.5kV DC, which protects sensitive equipment from electrical interference.
The converter operates within a wide temperature range from -40°C to +80°C, suitable for harsh industrial environments.
Yes, it includes a remote On/Off control feature, allowing for flexible operation management.
This model is designed for PCB mounting, making it easy to integrate into electronic systems.
It is typically used in mobile equipment, instrumentation, and distributed power architectures in communications and industrial electronics.
The mean time between failures (MTBF) for this unit is rated at 1.3 million hours, indicating long operational reliability.
It complies with safety standards UL/cUL 60950-1 and IEC/EN 60950-1, ensuring it meets industry safety requirements.
The output voltage can be adjusted within a range of ±10%, providing precise voltage regulation.
