Samtec TFM Series Straight Through Hole PCB Header 50 Contact 1.27 mm Pitch 2 Row Shrouded TFM-125-32-S-D-LC
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.2A |
| Model | TFM-125-32-S-D-LC |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TFM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 50 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
Key Features
- Constructed with black liquid crystal polymer housing for insulation.
- Features phosphor bronze contact material plated with gold for durability.
- Rated for 3.2A current per contact and 250V voltage.
- Designed for through hole mount and solder termination.
- Suitable for board-to-board connector systems with male contact gender.
- Operating temperature range from -55°C to 125°C ensures reliability.
- Shrouded straight orientation with 1.27 mm row pitch for precise PCB mounting.
Product Description
Samtec TFM-125-32-S-D-LC is a high-reliability straight through hole PCB header featuring 50 contact pins arranged in 2 rows with a 1.27 mm pitch. Manufactured with a black liquid crystal polymer housing, it provides excellent insulation and mechanical strength.
The contacts are made from phosphor bronze and plated with gold to ensure superior conductivity and corrosion resistance. Each contact supports a current rating of 3.2A and a voltage rating of up to 250V, suitable for demanding electronic applications.
This connector is designed for through hole mounting and uses solder termination, making it compatible with standard PCB assembly processes. The male contact gender and shrouded design provide secure and reliable board-to-board connections.
Operating reliably in temperatures ranging from -55°C to 125°C, this PCB header is ideal for industrial, electronic manufacturing, automotive, telecommunications, and consumer electronics uses. The 1.27 mm pitch and 2-row configuration enable high-density interconnectivity in compact PCBs.
Constructed with black liquid crystal polymer housing for insulation. Phosphor bronze contacts plated with gold provide excellent conductivity. 3.2A current rating and 250V voltage rating per contact ensure robust performance.
Straight, shrouded, through hole mount design with solder termination. Wide operating temperature range from -55°C to 125°C enables versatility. Optimized for board-to-board connector systems in electronic applications. 50 contacts arranged in 2 rows with 1.27 mm pitch support high-density connections.
This PCB header is a critical component in electronics assembly, offering secure mechanical retention and reliable electrical performance. It can be used in industrial electronics, communication devices, instrumentation, and other PCB-based systems requiring durable, high-quality connectors.
Explore our extensive range of PCB Headers and electronic components at EnvMart for your manufacturing and assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
Each contact of the Samtec TFM-125-32-S-D-LC PCB header supports a current rating of 3.2A and a voltage rating of up to 250V.
This model features a 1.27 mm pitch with 50 contact pins arranged in 2 rows.
The housing is constructed from black liquid crystal polymer, while the contacts are made from phosphor bronze and plated with gold.
It utilizes solder termination, making it suitable for standard PCB assembly processes.
The operating temperature range is from -55°C to 125°C, ensuring reliability in various environments.
This unit has a straight orientation, designed for through hole mounting.
It is optimized for board-to-board connector systems with male contact gender.
The Samtec TFM-125-32-S-D-LC features a total of 50 contacts.
The contact pitch is 1.27 mm, and the header is configured with 2 rows of contacts.
The country of origin for this PCB header is India.
It is suitable for industrial electronics, communication devices, instrumentation, and other PCB-based systems.
The contacts are plated with gold, providing excellent conductivity and corrosion resistance.
