MaxLinear Line Transceiver TTL Differential Single Ended Inverting 3.3V to 6V Supply 28-Pin TSSOP SP336ECY-L
Specifications
| Country of Origin | India |
|---|---|
| Brand | MaxLinear |
| Height | 1.2mm |
| Length | 9.8mm |
| Model | SP336ECY-L |
| Width | 4.5mm |
| Mount Type | Surface |
| Output type | TTL, Differential, Single Ended |
| Series | SP336E |
| Input Type | Single Ended, Differential |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Polarity | Inverting |
| IC Type | Line Transceiver |
| Standards/Approvals | IEC 61000-4-2 |
| Pin Count | 28 |
| Maximum Supply Voltage | 6V |
| Logic Family | TTL |
| Logic Function | Line Transceiver |
| Minimum Supply Voltage | 3.3V |
| Maximum High Level Output Current | -1.5mA |
| Maximum Propagation Delay Time @ CL | 1500ns |
| Supply Current | 30mA |
| Maximum Low Level Output Current | 2.5mA |
Key Features
- Operates with a supply voltage range of 3.3V to 6V ensuring versatility for various applications.
- Features inverting polarity with TTL, differential, and single ended output types.
- Comes in a compact 28-pin TSSOP surface mount package suitable for space-constrained designs.
- Guaranteed operation between -40°C and 85°C supporting industrial temperature ranges.
- Has a maximum propagation delay time of 1500ns at CL for reliable signal timing.
- Conforms to IEC 61000-4-2 standard for electrostatic discharge protection.
- Supply current is approximately 30mA for efficient power consumption.
- Designed for use in RS-232, RS-422, and RS-485 serial communication interfaces.
Product Description
MaxLinear SP336ECY-L is a Line Transceiver designed for TTL logic family with support for single ended and differential input types and inverting polarity. It operates from a supply voltage ranging from 3.3V to 6V and is housed in a compact 28-pin TSSOP surface mount package measuring 9.8mm x 4.5mm x 1.2mm.
This transceiver features a maximum propagation delay time of 1500ns and can handle maximum high level output current of -1.5mA and maximum low level output current of 2.5mA. Its supply current is 30mA making it suitable for efficient operation. The device is tested and approved under standard IEC 61000-4-2 for Electrostatic Discharge (ESD) protection.
Designed for industrial and commercial electronics, the SP336ECY-L is ideal for RS-232, RS-422, and RS-485 serial transceiver applications such as industrial and process control equipment, single board computers, point-of-sale systems, and building security and automation.
The compact surface mount TSSOP package aids board space optimization while ensuring reliable interfacing in multiprotocol transceiver designs. Operates with supply voltage between 3.3V and 6V. Supports inverting TTL, differential, and single ended outputs.
Complies with IEC 61000-4-2 for electrostatic discharge immunity. Operating temperature range from -40°C to 85°C ensures robustness in harsh environments. Ideal for industrial communication and automation applications. Compact 28-pin TSSOP surface mount package.
Explore more Line Interface ICs and related communication transceiver products at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports inverting TTL, differential, and single ended output types.
The maximum propagation delay time is 1500ns at CL, ensuring reliable signal timing.
It is guaranteed to operate between -40°C and 85°C, suitable for industrial applications.
It comes in a compact 28-pin TSSOP surface mount package, measuring 9.8mm x 4.5mm x 1.2mm.
The supply current is approximately 30mA, making it efficient for operation.
It conforms to the IEC 61000-4-2 standard for electrostatic discharge protection.
It supports both single ended and differential input types.
The maximum high level output current is -1.5mA.
The maximum low level output current is 2.5mA.
The country of origin is India.
