Texas Instruments Operational Amplifier 1 MHz 8-Pin 32V PDIP LM358N/NOPB
Specifications
| Country of Origin | Philippines |
|---|---|
| Brand | Texas Instruments |
| Height | 5.08mm |
| Length | 10.16mm |
| Model | LM358N/NOPB |
| Width | 6.6mm |
| Mount Type | Through Hole |
| Series | LM258-N |
| Output Current | 40mA |
| Maximum Operating Temperature | 70°C |
| Package Type | PDIP |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Maximum Supply Voltage | 32V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | 250 nA |
| Vos - Input Offset Voltage | 7 mV |
| Input Offset Current | 50 nA |
Key Features
- This device operates with a supply voltage range from 3V to 32V.
- It features a gain bandwidth product of 1 MHz suitable for various amplification tasks.
- The input offset voltage is 7 mV, with an input bias current of 250 nA for precision signal processing.
- Its output current capability is up to 40 mA for reliable signal drive.
- The operational temperature range spans from 0°C to 70°C, supporting standard industrial environments.
- The package dimensions are 10.16 mm length, 6.6 mm width, and 5.08 mm height in a PDIP form factor.
- This dual-channel amplifier IC is compliant with LM258-N series standards without automotive certification.
- Country of origin is Philippines, ensuring manufacturing quality standards.
Product Description
Texas Instruments LM358N/NOPB is a dual-channel operational amplifier designed for high-performance analog signal processing. Housed in an 8-pin PDIP package with dimensions 10.16 mm by 6.6 mm by 5.08 mm, it supports through-hole mounting for easy PCB integration.
Operating at frequencies up to 1 MHz with a gain bandwidth product of 1 MHz, this amplifier supports supply voltages from 3V to 32V, making it versatile for a wide range of electronic applications in signal amplification and conditioning.
The device delivers an output current up to 40 mA, with excellent input characteristics including a low input offset voltage of 7 mV, input offset current of 50 nA, and input bias current of 250 nA for precise analog signal manipulation.
Operating temperature ranges from 0°C to 70°C, suitable for typical commercial and industrial environments. The product meets the LM258-N series specifications and does not carry any special automotive compliance but is robust for general purpose use.
Manufactured in the Philippines, this operational amplifier is ideal for use in industrial electronics, laboratory instrumentation, signal conditioners, and general electronics designs needing reliable and stable analog amplification.
This operational amplifier supports dual channels in a compact package. It provides a stable 1 MHz gain bandwidth product for effective signal processing. Its wide supply voltage range ensures compatibility with diverse circuit designs.
The robust temperature operation range strengthens device reliability in industrial applications. Package and mounting style facilitate easy assembly and integration. EnvMart offers this Texas Instruments LM358N/NOPB Operational Amplifier for electronics professionals and designers seeking quality components for precision analog projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 1 MHz, suitable for various amplification tasks.
It operates with a supply voltage range from 3V to 32V, making it versatile for different circuit designs.
This model can deliver an output current of up to 40 mA, ensuring reliable signal drive.
The package dimensions are 10.16 mm in length, 6.6 mm in width, and 5.08 mm in height.
The input offset voltage is 7 mV, which is crucial for precision signal processing.
It has an operating temperature range from 0°C to 70°C, suitable for standard industrial environments.
This operational amplifier features two channels, allowing for dual-channel signal processing.
It supports through-hole mounting, facilitating easy integration into printed circuit boards (PCBs).
The input bias current is 250 nA, which contributes to its precision in analog signal manipulation.
It meets the specifications of the LM258-N series, ensuring compatibility with similar devices.
The input offset current is 50 nA, which is important for maintaining accuracy in signal processing.
This operational amplifier is manufactured in the Philippines, adhering to quality standards.
