onsemi Bridge Rectifier 100 V 35 A 4-Pin Single Surface Mount SOIC MB1S
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 2.7mm |
| Length | 4.95mm |
| Model | MB1S |
| Width | 4.2mm |
| Mount Type | Surface |
| Series | MB1S |
| Configuration | Single |
| Maximum Operating Temperature | 150°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -55°C |
| Number of Phases | 1 |
| Pin Count | 4 |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 35A |
| Forward Current If | 500mA |
| Peak Forward Voltage Vf | 1V |
| • Surge overload rating | 35A (peak) |
Key Features
- Supports a maximum forward current of 0.5 A with high surge absorption capabilities.
- Configured in a single bridge rectifier with 4 pins suitable for PCB mounting.
- Surge overload rating peaks at 35 A, ensuring robust transient current handling.
- Operates efficiently over a temperature range from -55°C to 150°C.
- Compact SOIC package dimensions of 4.95 mm length, 4.2 mm width, and 2.7 mm height.
- Low peak forward voltage of 1 V minimizes power losses.
- Designed without automotive certification, intended for general purpose power supply use.
- Absorbs surge currents effectively, with a 5.0 A²S fusing rating for reliability.
Product Description
The onsemi MB1S Bridge Rectifier is a high-quality Discrete Semiconductor device designed specifically for surface mount applications requiring reliable current rectification. This device is rated for a peak reverse repetitive voltage of 100 V and a forward current of 0.5 A, making it well suited for general purpose power supply circuits.
The compact SOIC package (4-pin) offers a space-saving design with precise dimensions of 4.95 mm in length, 4.2 mm in width, and 2.7 mm in height. Its single-phase configuration enables easy integration on printed circuit boards, while its peak non-repetitive forward surge current rating of 35 A ensures the device can withstand transient overloads without damage.
This bridge rectifier is designed to operate robustly across a broad temperature spectrum ranging from -55°C to 150°C. Its low forward voltage drop of 1 V minimizes power dissipation, making it efficient for continuous operation. The device also features low leakage current (peak reverse current of 500 μA), which enhances performance stability.
The MB1S series is ideal for applications requiring a compact, reliable rectification solution with high surge current absorption capacity. Its fusing rating of 5.0 A²S indicates enhanced protection against overcurrent conditions. While the device does not carry automotive certification, it complies with UL standards (E258596) and is suitable for a wide range of industrial, commercial, and power supply applications.
Key features include a compact SOIC package, high surge current tolerance, and broad operating temperature range. Typical uses encompass PCB-based power supply designs and transient voltage handling in electronic circuits.
Supports 0.5 A forward current with high surge current absorption. Rated peak reverse repetitive voltage of 100 V. Single-phase 4-pin surface mount SOIC package. Operates reliably between -55°C and 150°C. Peak surge overload rating of 35 A (non-repetitive).
Low forward voltage drop of 1 V for energy efficiency. UL compliance for quality assurance. Compact design ideal for PCB applications requiring high surge current capability. Low leakage current ensures minimal power loss in operation.
This onsemi MB1S Bridge Rectifier is a trusted choice for engineers and designers seeking a durable and efficient rectification component for various electronic and power supply projects. Browse additional semiconductor products and solutions on EnvMart for comprehensive electronics sourcing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak reverse repetitive voltage rating of this model is 100 V.
This bridge rectifier supports a maximum forward current of 0.5 A (500 mA).
The peak non-repetitive forward surge current rating is 35 A.
The SOIC package dimensions are 4.95 mm in length, 4.2 mm in width, and 2.7 mm in height.
It operates efficiently over a temperature range from -55°C to 150°C.
The MB1S is designed for surface mount applications.
The peak forward voltage drop is 1 V, which minimizes power losses during operation.
The peak reverse current rating is 500 μA.
Yes, it complies with UL standards (E258596).
It is suitable for general purpose power supply circuits and PCB-based power supply designs.
This model features a 4-pin configuration.
The fusing rating is 5.0 A²S, indicating enhanced protection against overcurrent conditions.
