| Country of Origin | India |
|---|---|
| Brand | Murata |
| Height | 0.8mm |
| Length | 1.6mm |
| Model | LQW18ANR10G00D |
| Depth | 0.8mm |
| Packaging | Paper Tape |
| Series | LQW |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Interfaces | LAN |
| Core Material | Ferrite |
| Inductance | 100nH |
| Standards/Approvals | RoHS |
| Package/Case | 0603 |
| Maximum DC Current | 220mA |
| Pin Count | 2 |
| Maximum DC Resistance | 680mΩ |
| Inductance Tolerance | ±2 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 1.8GHz |
| Minimum Quality Factor | 34 |
| Inductor Construction | Wirewound |
Murata LQW18ANR10G00D is a 0603 unshielded wirewound surface mount inductor featuring a ferrite core optimized for high frequency circuits with an inductance of 100 nH and a tight tolerance of ±2%. This inductor supports a maximum DC current of 220 mA and has a quality factor (Q) of 34, making it ideal for high resonance frequency applications such as VHF and UHF wireless telecommunication equipment including Bluetooth, GSM, and WLAN.
The inductor’s package size measures 1.6 mm in length and 0.8 mm in both height and depth, fitting standard surface mount design requirements. This component has a maximum DC resistance of 680 milliohms, ensuring efficient current flow with minimal losses. The device operates reliably within a temperature range from -55°C to 125°C, suitable for demanding industrial and electronic environments.
Constructed with a wirewound core material of ferrite, this RoHS-compliant inductor provides robust electromagnetic properties and environmental safety compliance. Its solder termination style facilitates secure and efficient PCB mounting. Packaged on paper tape, this component is ready for automated placement in manufacturing processes.
Typical industrial, laboratory, telecommunications, and electronics manufacturing applications benefit greatly from the Murata LQW18ANR10G00D inductor due to its performance and quality. This high-quality coil inductor is engineered for high-frequency resonance circuits requiring low tolerance and efficient current handling.
Compact 0603 surface mount package for space-saving PCB designs. Wirewound construction with ferrite core for high stability and performance. High maximum operating temperature of 125°C for robust applications. Inductance tolerance of ±2% ensures precise circuit performance.
RoHS certified for compliance with environmental directives. Maximum DC current rating of 220 mA suitable for wireless telecommunication circuits.
