HARTING D-Sub 26 Way Straight 2.29 mm Pitch Through Hole Female Connector with 4 to 40 UNC Threaded Insert 09562617712

HARTING 09562617712 is a high-performance D-Sub 26 Way Straight Connector featuring a 2.29 mm pitch and through hole mounting, designed for industrial and electronic applications demanding reliable connections.

Constructed with a steel housing, this connector includes gold-plated copper alloy female contacts ensuring excellent electrical conductivity and corrosion resistance. The 4 to 40 UNC threaded inserts provide secure and stable mounting, making it suitable for use in PCB assemblies and machinery installations.

Operating across a temperature range from -55°C to 105°C, it is engineered to withstand challenging environments typical in manufacturing, laboratory equipment, and automation systems. The connector supports current ratings up to 2A and can handle voltages up to 1kV, meeting performance level 3 standards.

The high-density contact layout exceeds standard D-Sub capacities by 70%, providing a compact solution without compromising on connectivity. Its solder termination type facilitates reliable and durable connections in through hole applications.

This D-Sub connector is designed with a high-density configuration accommodating 26 contacts. It features a straight orientation and uses solder termination for reliable electrical connections. The connector is constructed with a steel housing and gold-plated copper alloy contacts for enhanced durability and conductivity.

It supports an operating temperature range from -55°C to 105°C, suitable for harsh industrial environments. The connector includes flange thread hardware with 4 to 40 UNC threaded inserts for robust mounting. The contact pitch is 2.29 mm, matching industry standards for PCB connectors.

Designed for female connector gender and complies with D-Sub series specifications. Manufactured in China, the product is new and ready for industrial use.

This D-Sub connector is popular in electronics manufacturing, automation, instrumentation, and telecommunications industries. It is ideal for applications requiring compact, high-density connections, reliable electrical performance, and mechanical robustness.
