TDK 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 6.8 μH ±20 % 260 mA Idc NLFV32T-6R8M-EF
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | TDK |
| Height | 2.2mm |
| Operating Temperature Range | - 40 to +105°C (including self-temperature rise) |
| Length | 3.2mm |
| Model | NLFV32T-6R8M-EF |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | NLFV-EF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 6.8μH |
| Standards/Approvals | RoHS |
| Package/Case | 1210 |
| Maximum DC Current | 260mA |
| Maximum DC Resistance | 204mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 2.52MHz |
| Inductor Construction | Wirewound |
Key Features
- Compact 1210 package size suitable for surface mounting.
- Rated maximum DC current of 260 mA for reliable operation.
- Ferrite core with magnetic shield type resin mold construction enhances magnetic containment.
- Wide operating temperature range from -40°C to 105°C including self-temperature rise.
- Low maximum DC resistance of 204 mΩ reduces power loss.
- Maximum self-resonant frequency is 2.52 MHz under specified operating conditions.
- Supplied in tape & reel packaging for automated assembly processes.
- Termination style designed for surface mount applications.
Product Description
TDK NLFV32T-6R8M-EF is a high-quality shielded wirewound surface mount inductor designed for demanding electronic applications. Featuring a ferrite core and compact 1210 package size (3.2 mm length, 2.2 mm height, 2.5 mm depth), this inductor provides an inductance value of 6.8 μH with a tolerance of ±20 % and a maximum DC current rating of 260 mA. Its magnetic shield construction incorporates ferrite powder in the exterior mold resin, optimising magnetic containment and reducing interference.
This inductor operates reliably over an extended temperature range from -40°C to 105°C, including self-temperature rise, making it suitable for automotive, industrial, and telecommunications applications such as smart meters, AV equipment, xDSL, mobile base stations, and other communication infrastructure devices.
The component’s low DC resistance of 204 mΩ minimises power losses and improves efficiency. Its maximum self-resonant frequency of 2.52 MHz supports versatile frequency handling. The surface mount termination style facilitates its integration into automated PCB assembly lines, with tape & reel packaging further aiding efficient production.
Manufactured in Japan, the product complies with RoHS directives, ensuring environmentally responsible design and usage. The wirewound construction and resin mold casing provide mechanical robustness and stable electrical performance.
Compact 1210 SMT package for versatile electronic designs. 6.8 μH inductance with ±20 % tolerance supports precise circuit tuning. Ferrite core and magnetic shielding reduce electromagnetic interference. Wide operational temperature from -40°C to 105°C including self-heating.
Maximum DC current of 260 mA ensures dependable current handling. Low resistance of 204 mΩ improves energy efficiency. RoHS compliant for environmental safety. Suitable for smart meters, AV devices, xDSL, mobile base stations, and industrial electronics.
Supplied in tape & reel packaging for automated PCB mounting. Explore more Surface Mount Inductors and electronic components at EnvMart, trusted for industrial and commercial electronics needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 6.8 μH with a tolerance of ±20%.
The maximum DC current rating for this unit is 260 mA, ensuring reliable operation under specified conditions.
The dimensions of this inductor are 3.2 mm in length, 2.2 mm in height, and 2.5 mm in depth.
It operates within a temperature range of -40°C to 105°C, including self-temperature rise.
The maximum self-resonant frequency is 2.52 MHz under specified operating conditions.
This inductor features a ferrite core, which enhances its magnetic performance.
It is supplied in tape & reel packaging, facilitating automated assembly processes.
The maximum DC resistance is 204 mΩ, which helps to minimize power losses.
The termination style is designed for surface mount applications, making it suitable for PCB integration.
Yes, it is RoHS compliant, ensuring environmentally responsible design and usage.
This model is suitable for applications in automotive, industrial, and telecommunications, including smart meters and mobile base stations.
This inductor is part of the NLFV-EF series, which includes various surface mount inductors.
