TDK 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 330 μH ±10% 35 mA NLFV32T-331K-EF

The TDK NLFV32T-331K-EF is a high-quality 1210 shielded wirewound surface mount inductor featuring a ferrite core designed for reliable performance in compact electronic circuits. With an inductance of 330 μH and tolerance of ±10%, it offers consistent inductive properties essential for precise filtering and decoupling applications.

This inductor is constructed using a resin mold and includes a magnetic shield containing ferrite powder within the exterior mold resin, enhancing its immunity to electromagnetic interference. Its wirewound construction ensures durability and stable inductance over time.

Key mechanical dimensions are 3.2mm in length, 2.5mm in depth, and 2.2mm in height, fitting the standard 1210 surface mount package case for easy integration on PCBs. It features a maximum DC current rating of 35 mA and a maximum DC resistance of 8.16 ohms, suitable for low current signal conditioning and noise suppression tasks.

Performance is maintained across a wide operating temperature range from -40°C up to +105°C, inclusive of self-temperature rise, making it applicable for use in demanding environments like smart meters, audio-visual equipment, xDSL modems, mobile base stations, and other industrial and communication devices.

The inductor complies with RoHS standards, supporting environmentally conscious manufacturing and deployment. Packaging on tape and reel facilitates automated pick-and-place assembly, enhancing manufacturing efficiency.

Applications include power supply filtering, EMI suppression, and signal decoupling in electronic devices utilized in commercial, industrial, and telecommunications sectors. Constructed with a ferrite core and magnetic shield for enhanced performance.

Resin molded wirewound design suitable for decoupling circuits. Package size 1210 with dimensions 3.2mm length, 2.5mm depth, and 2.2mm height. Rated maximum DC resistance of 8.16 ohms and maximum self-resonant frequency of 2.52 MHz.

Operating temperature range from -40°C to 105°C including self-temperature rise. Surface mount termination style with tape and reel packaging for automated assembly. Compliance with RoHS standards ensuring environmental safety.

Ideal for applications in smart meters, AV equipment, xDSL, communications infrastructure, and industrial equipment. Explore the wide range of Surface Mount Inductors available on EnvMart to support your next electronic design project.
