Glenair MWDM 100 Way Straight 1.27 mm Pitch Panel Mount D-Sub Connector Female MWDM2L-100SSB

Glenair MWDM2L-100SSB is a 100 way straight D-Sub connector designed for panel mounting, with 1.27 mm pitch and female connector gender. It features a high-quality aluminum housing complemented by gold over nickel plated copper alloy contacts, ensuring reliable electrical connections with high conductivity and durability. This connector is suitable for environments with operating temperatures ranging from -55°C to 150°C, making it ideal for use in extreme conditions encountered in industrial, military, aerospace, and telecommunication applications.

The Micro-D connector series offers exceptional mechanical and electrical integrity even under intense vibration and harsh environmental conditions. The 3 Amp contact rating and high-density 0.050" contact pitch combined with high-performance liquid crystal polymer molded housing provide superior performance in critical systems.

The solder termination type with splayed solder cups supports 26 AWG cable and smaller sizes, improving ease of assembly. This connector meets the Mil-PRF-83513 and BS9523-F0002 standards, ensuring compliance with rigorous industry requirements.

Features 100 gold plated contacts ensuring excellent conductivity and corrosion resistance. Designed for panel mount with a straight orientation for ease of installation. Operates across a temperature range from -55°C to 150°C for versatile use.

Constructed with an aluminum housing offering durability and lightweight properties. Supports contact current rating up to 3 Amp for reliable electrical performance. Termination is via solder type with splayed solder cups to facilitate user assembly.

Suited for demanding applications including commercial, aerospace, military, industrial, and telecommunication systems. Complies with Mil-PRF-83513 and BS9523-F0002 standards.

This Glenair panel mount D-Sub Connector is designed to meet the highest standards of electrical and mechanical performance for demanding industrial, aerospace, and military uses. It benefits engineers and system integrators looking for robustness, reliability, and standard compliance in their connector solutions.
