3M 3000 Series Right Angle Through Hole PCB Header, 14 Contact(s), 2.54 mm Pitch, 2 Row, Shrouded N3314-5302RB
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 1V |
| Brand | 3M |
| Orientation | Right Angle |
| Current | 1.75 |
| Model | N3314-5302RB |
| Mount Type | Through Hole |
| Contact Material | Copper Alloy |
| Series | 3000 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 14 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 0.01in |
| Mating Pin Length | 6.2mm |
| 14 way IDC r/a std profile boxed headerBrand | 3M |
| HE10 PCB IDC r/a boxed header long 14WBrand | 3M |
Key Features
- Right angle orientation optimizes space in compact electronic assemblies.
- Shrouded construction enhances connection security and prevents accidental disconnections.
- Gold-plated copper alloy contacts ensure excellent conductivity and corrosion resistance.
- Designed for through-hole solder termination for strong, stable mounting.
- Rated for 1.75A current and 1000V voltage for moderate power applications.
- Operates reliably between -55°C and 105°C temperature range.
- Male contact gender with precise pin lengths of 0.01 in tail and 6.2 mm mating pins.
- Ideal for PCB interconnections in automation, control panels, mechanical, and consumer electronics.
Product Description
3M N3314-5302RB is a 3000 Series Right Angle Through Hole PCB Header designed for efficient electronic connections. Featuring 14 gold-plated contacts arranged in 2 rows with a 2.54 mm pitch, this male pin header supports both board-to-board and wire-to-board connector systems. Its shrouded design safeguards against accidental disconnection, making it suitable for robust industrial and commercial applications.
The connector supports a voltage rating of 1000V and a current capacity of 1.75A, ensuring dependable performance in moderate power circuits. Designed for through-hole mounting with solder termination, it facilitates secure and reliable PCB assembly. Operating temperature ranges from -55°C to 105°C, suitable for diverse environmental conditions.
Crafted from copper alloy with gold plating, the contacts deliver excellent conductivity and corrosion resistance, enhancing product longevity. The right-angle orientation allows compact PCB designs by optimizing space usage. This PCB header is widely used in automation systems, electrical control panels, mechanical systems, and consumer electronics, providing durable and precise interconnections.
Right angle orientation optimizes PCB real estate efficiently. Shrouded construction prevents misalignment and accidental disconnections. Gold-plated copper alloy contacts enhance conductivity and durability. Through-hole solder termination ensures strong mechanical and electrical bonds.
Rated for 1.75A current and 1000V voltage suitable for various applications. Operates reliably in temperature extremes from -55°C to 105°C. Ideal for industrial, laboratory, HVAC, manufacturing, and consumer electronics use.
Facilitates secure board-to-board and wire-to-board connections.
This product is manufactured in the United States, ensuring quality and reliability expected from 3M. Suitable for engineers and technicians requiring high-quality PCB headers with dependable electrical and mechanical performance. Explore more from 3M in the PCB Header category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a voltage of 1000V, making it suitable for moderate power applications.
It has a current capacity of 1.75A, which is appropriate for various electrical applications.
The operating temperature range is from -55°C to 105°C, allowing it to function in diverse environmental conditions.
This model features 14 contacts arranged in 2 rows with a 2.54 mm pitch.
It uses a through-hole solder termination type, ensuring a strong and stable mounting on PCBs.
The contacts are made from copper alloy and are gold-plated to enhance conductivity and corrosion resistance.
This model features a right angle orientation, which optimizes space in compact electronic assemblies.
It is a shrouded connector, which helps prevent accidental disconnections and misalignment.
It supports both board-to-board and wire-to-board connector systems, making it versatile for various applications.
The tail pin length is 0.01 inches, while the mating pin length is 6.2 mm.
This PCB header is manufactured in the United States, ensuring quality and reliability.
It is ideal for use in automation systems, electrical control panels, mechanical systems, and consumer electronics.
