Samtec TLW Series Straight Through Hole Pin Header 16 Contacts 2.54 mm Pitch 1 Row Unshrouded TLW-116-06-T-S
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Current | 5.2A |
| Model | TLW-116-06-T-S |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TLW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 1.52mm |
| Mating Pin Length | 2.67mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Features a 2.54 mm pitch for precise board-to-board connection.
- Comprises 16 male contacts in a single row for efficient signal transmission.
- Housing made from Liquid Crystal Polymer for durability and stability.
- Constructed with phosphor bronze contacts plated with tin for corrosion resistance.
- Suitable for through-hole mounting with solder termination ensuring secure attachment.
- Designed for operating temperatures ranging from -55°C to 125°C, dependable in extreme conditions.
- Supports a maximum current of 5.2 amperes per contact for robust electrical performance.
- Contact system utilizes 0.025 inch (0.635 mm) square posts for reliable engagement.
Product Description
Samtec TLW-116-06-T-S is a high-quality, straight through hole pin header designed for reliable electronic board connections. This component features 16 male contacts arranged in a single row with a 2.54 mm pitch, making it suitable for precise board-to-board interfacing in electronic assemblies.
The housing is made from Liquid Crystal Polymer, offering excellent mechanical strength and heat resistance, while the phosphor bronze contacts plated with tin ensure durability and corrosion resistance during operation.
This pin header is designed for through-hole mounting and employs solder termination for robust and secure attachment to printed circuit boards. It is rated for a current capacity of 5.2 amperes per contact and can reliably operate in temperature ranges from -55°C to 125°C, supporting a wide variety of industrial and electronic environments.
The contact system uses 0.025 inch (0.635 mm) square posts, with tail pin and mating pin lengths of 1.52 mm and 2.67 mm respectively, ensuring optimal mechanical and electrical connection integrity.
Features a 2.54 mm pitch for precise board-to-board connection. Comprises 16 male contacts in a single row for efficient signal transmission. Housing made from Liquid Crystal Polymer for durability and stability. Constructed with phosphor bronze contacts plated with tin for corrosion resistance.
Suitable for through-hole mounting with solder termination ensuring secure attachment. Designed for operating temperatures ranging from -55°C to 125°C, dependable in extreme conditions. Supports a maximum current of 5.2 amperes per contact for robust electrical performance.
Contact system utilizes 0.025 inch (0.635 mm) square posts for reliable engagement. Tail pin length of 1.52 mm and mating pin length of 2.67 mm for optimal mechanical fit. Ideal for diverse electronic applications requiring board-to-board connections in industrial and commercial equipment.
This through-hole pin header from the Samtec TLW series is widely used in electronic manufacturing, industrial machinery, telecommunications, and consumer electronics due to its reliable connectivity and robust design.
Explore more high-quality PCB connectors and accessories on EnvMart to complete your electronic assembly needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header is 2.54 mm, allowing for precise board-to-board connections.
This model features 16 male contacts arranged in a single row.
Each contact supports a maximum current of 5.2 amperes.
The housing is made from Liquid Crystal Polymer, and the contacts are constructed from phosphor bronze plated with tin for corrosion resistance.
It is designed to operate within a temperature range of -55°C to 125°C.
This pin header is designed for through-hole mounting with solder termination, ensuring a secure attachment to printed circuit boards.
The tail pin length is 1.52 mm, while the mating pin length is 2.67 mm.
This model is unshrouded, allowing for easier access to the contacts during installation.
The connector system is designed for board-to-board connections.
The contact system utilizes 0.025 inch (0.635 mm) square posts for reliable engagement.
This pin header is part of the Samtec TLW series.
The country of origin for this pin header is India.
