Samtec SMM Series Right Angle Surface PCB Socket 6-Contact, 2 Row, 2 mm Pitch, 350 V, 3.2 A Solder Termination SMM-103-02-S-D

Samtec SMM-103-02-S-D is a high-quality right angle surface PCB socket designed for board-to-board connections requiring reliable electrical performance. This PCB socket comprises 6 female contacts in 2 rows with a 2 mm pitch, optimized for use in electronic components and power connectors.

The housing is made of advanced Liquid Crystal Polymer, which offers excellent mechanical stability and thermal resistance. The contact system utilizes the patented Tiger Eye™ multi-finger beryllium copper alloy contacts with gold plating, enhancing conductivity and corrosion resistance for demanding industrial applications.

This socket supports a continuous current rating of 3.2 A and can withstand voltages up to 350 V, ensuring suitability for a wide range of electronic assemblies. Its surface mount solder termination and right angle orientation allow for compact PCB mounting and space-saving designs.

Operating temperature ranges from -55°C to 125°C, making it suitable for environments with temperature fluctuations such as manufacturing, industrial electronics, and communications equipment. The socket features a 1.27 mm row pitch and a 2 mm contact pitch, providing precise alignment and robust electrical contact.

Additional benefits include its high-reliability multi-finger contact system, which delivers excellent mating cycles and low contact resistance. This product is manufactured in the United States, adhering to high-quality standards for PCB connector systems.

The socket supports a current rating of 3.2 A and voltage rating up to 350 V. Manufactured with a Liquid Crystal Polymer housing and gold-plated beryllium copper alloy contacts ensure durability and reliability. Designed with Tiger Eye™ high-reliability multi-finger contact system for secure electrical connection.

Suitable for operating temperatures ranging from -55°C to 125°C. Terminates via surface mount soldering with a right angle orientation for space-efficient PCB designs. Female contact gender and 1.27 mm row pitch provide compatibility with appropriate board layouts.

This Samtec PCB socket is ideal for electronics manufacturing, industrial automation, telecommunications, and other commercial PCB assembly applications. Explore more PCB Socket and connector options in the Electronics Components category at EnvMart.
