Microchip MOSFET Gate Driver 1.5 A Dual Output 8-Pin MSOP 18V MIC4427YMM

Name: Microchip MOSFET Gate Driver 1.5 A Dual Output 8-Pin MSOP 18V MIC4427YMM
Brand: Microchip
SKU: 97772
Price: 1.14 USD
Availability: InStock



Category MOSFET Gate Driver Brand Microchip Condition New

Specifications

Country of Origin	India
Brand	Microchip
Height	0.81mm
Length	3.1mm
Model	MIC4427YMM
Width	3.05mm
Mount Type	Surface
Series	MIC4427
Output Current	1.5A
Maximum Operating Temperature	85°C
Package Type	MSOP
Minimum Operating Temperature	-40°C
Number of outputs	2
Rise Time	40ns
Pin Count	8
Minimum Supply Voltage	18V
Number of Drivers	2
Fall Time	40ns
Driver Type	MOSFET

Key Features

Supports dual low-side MOSFET driving with matched rise and fall times for efficient switching.
Features bipolar/CMOS/DMOS construction with latch-up protection exceeding 500mA reverse current.
Operates in a wide voltage range from 4.5V to 18V with low quiescent current consumption.
Offers fast switching performance with rise and fall times of 40ns, enabling high-speed applications.
Compact dimensions of 3.1mm length, 3.05mm width, and 0.81mm height suit space-constrained electronic designs.
Designed for surface mount applications with automotive standard compliance not applicable.
Capable of switching 1000pF load capacitance in approximately 25ns, ensuring optimal performance.
Provides 7Ω output impedance for stable operation and effective MOSFET gate drive.

Product Description

Microchip MIC4427YMM is a highly reliable dual low-side MOSFET gate driver fabricated using BiCMOS/DMOS process technology for enhanced efficiency and low power consumption. It is designed to translate TTL or CMOS input logic levels to output voltage levels that swing within 25mV of the supplied voltage or ground, providing precise gate drive for MOSFET devices.

The device offers 1.5 A peak output current with fast rise and fall times of 40ns, suitable for high-speed switching applications in various electronic and power management systems. It supports an operating voltage range of 4.5V up to a maximum of 18V with low quiescent supply current, ensuring minimal power wastage.

Featuring bipolar/CMOS/DMOS construction and latch-up protection to over 500mA reverse current, the MIC4427YMM enhances durability and reliability in industrial, automotive, and commercial electronic circuits. The package is a compact 8-pin MSOP surface mount type, measuring 3.1mm x 3.05mm x 0.81mm, ideal for space-saving PCB layouts.

This model supports dual output drivers with matched rise and fall times and 7Ω output impedance, enabling smooth and stable MOSFET switching. It can switch capacitive loads of 1000pF within 25ns, ensuring superior performance in power management IC applications.

Dual low-side MOSFET driver with 1.5 A peak current and dual output. BiCMOS/DMOS technology for low power consumption and high efficiency. Latch-up protection exceeding 500mA reverse current for enhanced reliability. Wide supply voltage range from 4.5V to 18V, accommodating various circuit requirements.

Compact 8-pin MSOP surface mount package for space-efficient installations. Fast switching with 40ns rise and fall times and matched timings. Low quiescent current consumption at logic high and low levels. Industrial and commercial electronics suitable applications.

This Microchip gate driver is suitable for industrial power management, electronic device switching, laboratory equipment, and automotive electronic control systems that require efficient and rapid MOSFET driving capabilities.

Explore more Microchip semiconductor solutions and MOSFET Gate Drivers on EnvMart for your industrial electronics needs.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model provides a peak output current of 1.5 A, making it suitable for driving MOSFETs efficiently.

The MIC4427YMM operates within a voltage range of 4.5V to 18V, accommodating various circuit requirements.

It features rise and fall times of 40ns, enabling high-speed switching applications.

This model has compact dimensions of 3.1mm in length, 3.05mm in width, and 0.81mm in height, suitable for space-constrained designs.

It is designed with dual outputs, allowing for efficient control of two low-side MOSFETs simultaneously.

This model is packaged in an 8-pin MSOP surface mount configuration, ideal for compact PCB layouts.

It provides an output impedance of 7Ω, ensuring stable operation during MOSFET gate driving.

The maximum operating temperature for this model is 85°C, suitable for various industrial applications.

The MIC4427YMM can operate at a minimum temperature of -40°C, making it versatile for different environments.

It features a BiCMOS/DMOS construction, which enhances efficiency and reduces power consumption.

This model is capable of switching a load capacitance of 1000pF in approximately 25ns, ensuring optimal performance.

It is suitable for various applications including industrial power management, electronic device switching, and automotive electronic control systems.
