Block 2 Output 100 VA Chassis Mount Transformer, 2 x 12 V ac, VDE 0570 Teil 2-6, UL 5085-1/-2, IEC 61558-2-2 STEU100/24

Free Delivery in India | Lowest Global Shipping Charges

Block 2 Output 100 VA Chassis Mount Transformer, 2 x 12 V ac, VDE 0570 Teil 2-6, UL 5085-1/-2, IEC 61558-2-2 STEU100/24

Name: Block 2 Output 100 VA Chassis Mount Transformer, 2 x 12 V ac, VDE 0570 Teil 2-6, UL 5085-1/-2, IEC 61558-2-2 STEU100/24
Brand: Block
SKU: 96910
Price: 117.51 USD
Availability: InStock



Category Chassis Mount Transformer Brand Block Condition New

Specifications

Country of Origin	Germany
Brand	Block
Length	84mm
Model	STEU100/24
Depth	85mm
Gross Weight	2.1kg
Width	84mm
Series	STEU 100/24
Maximum Operating Temperature	40°C
Number of outputs	2
Primary Voltage	230 V, 400 V ac
Secondary Voltage	2 x 12 V ac
Minimum Operating Frequency	50Hz
Maximum Operating Frequency	60Hz

Key Features

This transformer offers two secondary outputs of 12 V ac each.
Designed for chassis mounting with easy installation via 4 hole panel mount fixings.
Supports primary voltages of 230 V and 400 V ac with a maximum operating temperature of 40°C.
Includes a twin secondary winding suitable for series or parallel connection.
Equipped with 4mm² cage clamp terminals for robust connections.
Low inrush current and high efficiency with low voltage regulation.
Meets multiple standards including VDE, UL, IEC, and cURus approvals for safety and reliability.
Compact dimensions of 84mm x 85mm x 84mm with a weight of 2.1 kg.

Product Description

Block STEU100/24 chassis mount transformer is a precision engineered 100 VA power transformer featuring dual 12 V ac outputs designed for industrial and commercial electrical applications. Built to comply with international safety and quality standards including VDE 0570 Teil 2-6, UL 5085-1/-2, IEC 61558-2-2, and cURus certifications, it ensures reliable operation and safety in isolating, control, and power distribution tasks.

This unit supports dual primary voltages of 230 V and 400 V ac and operates efficiently within a frequency range of 50 Hz to 60 Hz. Its twin secondary winding permits flexible configuration through series or parallel connections, catering to versatile application requirements.

The transformer’s robust chassis mount design includes four-hole panel mount fixings and 4mm² cage clamp terminals which facilitate straightforward installation and strong electrical connections. Its insulation category is Class B, and it features low inrush current to reduce stress on power systems.

Dimensions are compact at 84 mm length, 85 mm depth, and 84 mm width, weighing approximately 2.1 kg, allowing easy integration into existing equipment setups. Suitable for use in industrial machines, laboratory instruments, HVAC systems, and power supply units, it is a dependable choice for safety isolating transformer needs.

This transformer offers two secondary outputs of 12 V ac each. Designed for chassis mounting with easy installation via 4 hole panel mount fixings. Supports primary voltages of 230 V and 400 V ac with a maximum operating temperature of 40°C.

Includes a twin secondary winding suitable for series or parallel connection. Equipped with 4mm² cage clamp terminals for robust connections. Low inrush current and high efficiency with low voltage regulation. Meets multiple standards including VDE, UL, IEC, and cURus approvals for safety and reliability.

Compact dimensions of 84mm x 85mm x 84mm with a weight of 2.1 kg. Choose Block STEU100/24 for trusted, high-quality Chassis Mount Transformer solutions available on EnvMart.
