Vishay Polypropylene Capacitor X2, 220 nF, ±20 % Tolerance, 630 V dc 305 V ac, Radial Through Hole F339X242230MFM2B0
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 16.5mm |
| Length | 17.5mm |
| Model | F339X242230MFM2B0 |
| Packaging | Bulk |
| Width | 10mm |
| Mount Type | Through Hole |
| Series | F339X2 |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±20 % |
| Capacitance | 220nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Radial |
| Lead Length | 5mm |
| Pin Count | 2 |
| Rated AC Voltage | 305V ac |
| Rated DC Voltage | 630V dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q200 |
| Suppression Class | X2 |
Key Features
- Rated DC voltage is 630 V and rated AC voltage is 305 V for robust performance.
- Suppression class X2 suited for interference suppression in electrical circuits.
- Lead pitch measures 15 mm with 2 radial pins for secure connection.
- Operating temperature range spans from -40°C up to 105°C ensuring reliability in harsh environments.
- Compliant with automotive standard AEC-Q200 and multiple international approvals including UL 60384-14 and IEC standards.
- Packaging supplied in bulk suitable for industrial and manufacturing use.
Product Description
Vishay F339X242230MFM2B0 is a high-quality polypropylene film capacitor designed for through hole radial mounting, offering 220 nF capacitance with ±20 % tolerance. It is suitable for AC voltage rated at 305 V and DC voltage rated at 630 V, making it ideal for interference suppression in electrical circuits under class X2.
This capacitor features a lead pitch of 15 mm and two radial pins with a lead length of 5 mm and diameter of 0.8 mm, facilitating easy PCB integration. Its operating temperature range from -40°C to 105°C ensures stable performance in diverse industrial environments.
Certified to international standards such as UL 60384-14, IEC 60065, CSA E384-14, CQC, and meets automotive standard AEC-Q200, this capacitor guarantees reliability and compliance for automotive and general electronic applications.
Rated DC voltage of 630 V provides a strong withstand capability in circuits. Rated AC voltage of 305 V across the line enhances suppression of electrical interference. Standard X2 suppression class capacitor suitable for mains interference.
Compact size with 17.5 mm length, 10 mm width, and 16.5 mm height for efficient space usage. Operates reliably in temperature range -40°C to 105°C for various industrial and automotive uses. Bulk packaging facilitates large volume consumption in manufacturing setups.
Radial terminal type simplifies assembly and soldering processes.
Applications include industrial, automotive, power electronics, and HVAC systems requiring high-quality interference suppression capacitors. The Vishay F339X2 series capacitors are trusted in demanding environments for stable electrical performance and longevity.
Explore a wide selection of Film Capacitors and related electronic components on EnvMart for your manufacturing and repair needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 220 nF with a tolerance of ±20%.
It has a rated DC voltage of 630 V and a rated AC voltage of 305 V.
The operating temperature range spans from -40°C to 105°C, making it suitable for various industrial environments.
The lead pitch measures 15 mm, which facilitates secure connections during installation.
This model is designed for through hole mounting, featuring radial terminals for easy assembly.
It has a length of 17.5 mm, a width of 10 mm, and a height of 16.5 mm.
Yes, it is compliant with the automotive standard AEC-Q200, ensuring reliability for automotive applications.
It is classified as an X2 suppression class capacitor, suitable for interference suppression in electrical circuits.
The country of origin for this model is India.
The lead length is 5 mm with a lead diameter of 0.8 mm, which aids in PCB integration.
It is supplied in bulk packaging, which is suitable for industrial and manufacturing use.
This capacitor is suitable for applications in industrial, automotive, power electronics, and HVAC systems requiring high-quality interference suppression.
