Crydom 8413 Series Solid State Relay, 75 Arms Load, Panel Mount, 280 V ac Load, 32V dc Control 84137030

Crydom 84137030 is a high-performance 8413 Series Solid State Relay designed for industrial and automation applications requiring reliable AC switching capabilities. This panel mount relay supports a robust load current of 75 Arms and a maximum load voltage of 280 V AC. The control input voltage ranges from 3 V DC up to 32 V DC, enabling compatibility with various automation control systems.

This relay utilizes SCR output technology combined with zero cross switching functionality to reduce electrical noise and prolong system life. Its compact size, with dimensions of 30.9 mm height and 44.5 mm length, allows easy installation within electrical control panels. The device features screw terminal connections for secure wiring and flexible integration.

The solid state relay is rated for an IP20 ingress protection level, protecting it from ingress of solid objects and minor contact. It is suitable for applications operating within a wide temperature range from -40°C up to 80°C, making it reliable in diverse industrial environments. The relay includes important safety and compliance certifications such as UL and CE, ensuring dependable performance and compliance with international standards.

Additional features include an LED input status indicator for easy visual monitoring, anti-rotation barriers enhancing mounting stability, overvoltage protection on all AC output variants, and improved thermal performance using DBC technology. The Crydom 8413 Series SSR offers enhanced SEMS screw fasteners and washers, increasing durability and ease of installation. It complies with EMC level 3 regulations, assuring minimal electromagnetic interference.

Typical industrial applications include automation control systems, electrical panel switching, HVAC control, manufacturing equipment integration, and other electrical load control situations requiring dependable solid state switching with high current ratings. The compact and efficient design supports seamless integration into panel mount environments for professional electrical systems.

Supports maximum load current of 75 Arms for demanding applications. Panel mount type ensures easy integration into electrical panels. Operates with load voltage up to 280 V AC and minimum load of 24 V AC. Control voltage range from 3 V DC minimum to 32 V DC maximum for flexible control.

Features zero cross switching to minimize electrical noise during operation. Robust SCR output type with low off-state leakage current of 0.1 mArms. Compact dimensions with height 30.9 mm and length 44.5 mm. Designed with IP20 rating ensuring protection against solid objects.

Operates reliably in temperatures from -40°C to 80°C. Equipped with screw terminal type and certified with UL and CE standards.
