HARTING D-Sub 15 Way Right Angle Through Hole Solder Female Connector with 4 to 40 UNC Screw Lock 09682535613
Specifications
| Country of Origin | China |
|---|---|
| Brand | HARTING |
| Orientation | Right Angle |
| Current | 6.5A |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Thermoplastic |
| Contact Material | Copper Alloy |
| Series | D-Sub |
| Mounting Hardware | 4 to 40 UNC Screw Lock |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Steel |
| Number of Contacts | 15 |
| Contact Gender | Female |
| Connector Gender | Female |
| Connector Type D | D-Sub |
Key Features
- This connector has 15 female contacts rated for 6.5A current.
- It features a robust fibreglass reinforced thermoplastic housing.
- Designed with right angle orientation for through-hole mounting.
- Contact plating is steel over copper alloy contacts ensuring durability.
- Operates reliably between -55°C to 125°C temperature range.
- Equipped with a U.S. footprint and extra grounding pin for improved performance.
- Suitable for applications requiring sturdy and secure connections in electronic assemblies.
- Standard mounting hardware for panel fixing with screw lock included.
Product Description
HARTING 09682535613 is a D-Sub 15 Way Right Angle Female Connector designed for reliable solder termination and through-hole mounting in electronic circuits. This connector features a fibreglass reinforced thermoplastic housing that offers robust mechanical protection and high-temperature resistance from -55°C to 125°C.
The 15 copper alloy female contacts with steel plating provide a durable and corrosion-resistant interface capable of handling currents up to 6.5A. Its right angle orientation and 4 to 40 UNC screw lock mounting hardware ensure secure and stable panel installation. The inclusion of an extra grounding pin and compliance with a U.S. footprint standard enhance electrical performance and reliability.
This connector is ideal for use in electronic component assemblies, industrial automation, instrumentation, and communication equipment where high-quality, long-lasting connections are required. It is manufactured in China to strict quality standards but does not carry specific certifications.
This connector has 15 female contacts rated for 6.5A current. Fibreglass reinforced thermoplastic housing ensures durability. Right angle orientation for through-hole mounting. 4 to 40 UNC screw lock hardware for secure fixing.
Operating temperature range from -55°C to 125°C. Copper alloy contacts with steel plating for long life. Extra grounding pin for enhanced safety and performance. Compliant with U.S. footprint standard for D-Sub Connectors.
Explore the range of HARTING connectors and reliable electronic components at EnvMart for diverse industrial, manufacturing, and electronic assembly requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This D-Sub connector has a current rating of 6.5A.
It operates reliably within a temperature range of -55°C to 125°C.
The housing is made of fibreglass reinforced thermoplastic, while the contacts are copper alloy with steel plating.
It features through-hole mounting with 4 to 40 UNC screw lock hardware for secure installation.
This model has 15 female contacts.
The connector is designed with a right angle orientation.
It utilizes solder termination for reliable connections.
Yes, it includes an extra grounding pin for enhanced safety and performance.
This connector is manufactured in China.
It is suitable for electronic component assemblies, industrial automation, instrumentation, and communication equipment.
This model is a D-Sub connector with female gender contacts.
